| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T01_9000002312_15600cztM0_level2.evt | modeM0/AS1A04_037T01_9000002312_15600cztM0_level2_quad_clean.evt |
| Size (bytes) | 441,619,200 | 95,811,840 |
| Size | 421.2 MB | 91.4 MB |
| Events in quadrant A | 3,257,693 | 613,428 |
| Events in quadrant B | 3,191,391 | 631,633 |
| Events in quadrant C | 3,388,683 | 609,959 |
| Events in quadrant D | 3,097,038 | 595,445 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13839 | 3 |
| B | 0 | 13597 | 2 |
| C | 0 | 13943 | 2 |
| D | 0 | 13561 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6472 | 32 | 0.494438% |
| B | 6472 | 21 | 0.324475% |
| C | 6472 | 59 | 0.911619% |
| D | 6472 | 25 | 0.386279% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7608 | 6474 | 20 | 20 | 0.26% | 0.31% |  |
| B | 7608 | 6474 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7608 | 6474 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7608 | 6474 | 6 | 6 | 0.08% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 126819 | 791.7 | 793 | 777 | 159.2 |
| A | 0 | 253 | 58842 | 364.72 | 793 | 777 | 159.2 |
| A | 15 | 157 | 14973 | 89.17 | 793 | 777 | 159.2 |
| B | 12 | 111 | 17617 | 110.37 | 800 | 778 | 152.6 |
| B | 11 | 111 | 15142 | 94.15 | 800 | 778 | 152.6 |
| B | 0 | 189 | 13290 | 82.01 | 800 | 778 | 152.6 |
| C | 3 | 233 | 222916 | 1220.45 | 777 | 785 | 182.0 |
| C | 14 | 238 | 120214 | 656.17 | 777 | 785 | 182.0 |
| C | 0 | 207 | 7509 | 36.94 | 777 | 785 | 182.0 |
| D | 12 | 222 | 55246 | 282.4 | 785 | 761 | 192.9 |
| D | 2 | 234 | 29883 | 150.94 | 785 | 761 | 192.9 |
| D | 15 | 145 | 17707 | 87.83 | 785 | 761 | 192.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
