| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T01_9000002312_15603cztM0_level2.evt | modeM0/AS1A04_037T01_9000002312_15603cztM0_level2_quad_clean.evt |
| Size (bytes) | 489,191,040 | 106,369,920 |
| Size | 466.5 MB | 101.4 MB |
| Events in quadrant A | 3,525,567 | 700,110 |
| Events in quadrant B | 3,884,048 | 712,241 |
| Events in quadrant C | 3,512,405 | 679,683 |
| Events in quadrant D | 3,445,500 | 669,431 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14322 | 3 |
| B | 0 | 15671 | 2 |
| C | 0 | 14296 | 2 |
| D | 0 | 14230 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6597 | 77 | 1.167197% |
| B | 6597 | 107 | 1.621949% |
| C | 6597 | 109 | 1.652266% |
| D | 6597 | 84 | 1.273306% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7918 | 6598 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7918 | 6598 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7918 | 6598 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7918 | 6598 | 14 | 14 | 0.18% | 0.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 253 | 61278 | 341.74 | 891 | 875 | 176.7 |
| A | 4 | 2 | 21877 | 118.82 | 891 | 875 | 176.7 |
| A | 0 | 226 | 8209 | 41.49 | 891 | 875 | 176.7 |
| B | 4 | 251 | 363146 | 2200.12 | 879 | 860 | 164.7 |
| B | 4 | 173 | 22622 | 132.16 | 879 | 860 | 164.7 |
| B | 3 | 209 | 19026 | 110.32 | 879 | 860 | 164.7 |
| C | 14 | 238 | 131734 | 664.35 | 856 | 866 | 197.0 |
| C | 3 | 233 | 23085 | 112.79 | 856 | 866 | 197.0 |
| C | 7 | 247 | 8158 | 37.02 | 856 | 866 | 197.0 |
| D | 12 | 110 | 47010 | 217.34 | 877 | 853 | 212.4 |
| D | 10 | 70 | 33045 | 151.58 | 877 | 853 | 212.4 |
| D | 2 | 234 | 28161 | 128.59 | 877 | 853 | 212.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
