| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T01_9000002312_15605cztM0_level2.evt | modeM0/AS1A04_037T01_9000002312_15605cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,402,880 | 82,837,440 |
| Size | 451.5 MB | 79.0 MB |
| Events in quadrant A | 3,701,931 | 513,500 |
| Events in quadrant B | 3,643,441 | 529,351 |
| Events in quadrant C | 3,298,794 | 503,448 |
| Events in quadrant D | 3,243,952 | 501,170 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14854 | 2 |
| B | 0 | 14597 | 1 |
| C | 0 | 13691 | 1 |
| D | 0 | 13774 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6604 | 191 | 2.892187% |
| B | 6604 | 83 | 1.256814% |
| C | 6604 | 77 | 1.165960% |
| D | 6604 | 71 | 1.075106% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7725 | 6605 | 70 | 70 | 0.91% | 1.06% |  |
| B | 7725 | 6606 | 5 | 5 | 0.06% | 0.08% |  |
| C | 7725 | 6606 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7725 | 6605 | 22 | 22 | 0.28% | 0.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 253 | 264096 | 1563.61 | 835 | 817 | 168.4 |
| A | 4 | 2 | 214609 | 1269.71 | 835 | 817 | 168.4 |
| A | 15 | 239 | 8672 | 46.65 | 835 | 817 | 168.4 |
| B | 4 | 251 | 241981 | 1534.95 | 830 | 811 | 157.1 |
| B | 4 | 173 | 41156 | 256.78 | 830 | 811 | 157.1 |
| B | 15 | 201 | 31216 | 193.52 | 830 | 811 | 157.1 |
| C | 14 | 238 | 124478 | 661.05 | 803 | 810 | 187.1 |
| C | 3 | 233 | 18649 | 95.36 | 803 | 810 | 187.1 |
| C | 0 | 207 | 14882 | 75.22 | 803 | 810 | 187.1 |
| D | 13 | 172 | 56999 | 283.09 | 825 | 804 | 198.5 |
| D | 2 | 234 | 31027 | 152.25 | 825 | 804 | 198.5 |
| D | 10 | 70 | 16839 | 80.78 | 825 | 804 | 198.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
