| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_088T01_9000002320_15689cztM0_level2.evt | modeM0/AS1T02_088T01_9000002320_15689cztM0_level2_quad_clean.evt |
| Size (bytes) | 477,406,080 | 76,187,520 |
| Size | 455.3 MB | 72.7 MB |
| Events in quadrant A | 3,347,179 | 466,614 |
| Events in quadrant B | 3,408,153 | 484,054 |
| Events in quadrant C | 3,552,583 | 461,536 |
| Events in quadrant D | 3,716,883 | 449,151 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13738 | 3 |
| B | 0 | 13821 | 2 |
| C | 0 | 14220 | 2 |
| D | 0 | 14966 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6386 | 52 | 0.814281% |
| B | 6386 | 43 | 0.673348% |
| C | 6386 | 81 | 1.268400% |
| D | 6386 | 87 | 1.362355% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7697 | 6388 | 26 | 26 | 0.34% | 0.41% |  |
| B | 7697 | 6388 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7697 | 6388 | 5 | 5 | 0.06% | 0.08% |  |
| D | 7697 | 6388 | 65 | 65 | 0.84% | 1.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 124239 | 740.04 | 833 | 818 | 166.8 |
| A | 4 | 2 | 11707 | 65.29 | 833 | 818 | 166.8 |
| A | 0 | 226 | 7346 | 39.14 | 833 | 818 | 166.8 |
| B | 4 | 173 | 62104 | 387.01 | 846 | 827 | 158.3 |
| B | 12 | 111 | 18027 | 108.63 | 846 | 827 | 158.3 |
| B | 11 | 111 | 15428 | 92.22 | 846 | 827 | 158.3 |
| C | 3 | 233 | 200632 | 1076.8 | 810 | 818 | 185.6 |
| C | 14 | 238 | 127610 | 683.29 | 810 | 818 | 185.6 |
| C | 0 | 207 | 53955 | 286.36 | 810 | 818 | 185.6 |
| D | 1 | 52 | 369491 | 1892.17 | 809 | 789 | 194.9 |
| D | 10 | 70 | 249265 | 1275.17 | 809 | 789 | 194.9 |
| D | 2 | 234 | 22383 | 110.82 | 809 | 789 | 194.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
