| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_030T01_9000002326_15729cztM0_level2.evt | modeM0/AS1G08_030T01_9000002326_15729cztM0_level2_quad_clean.evt |
| Size (bytes) | 445,196,160 | 93,640,320 |
| Size | 424.6 MB | 89.3 MB |
| Events in quadrant A | 3,064,825 | 606,590 |
| Events in quadrant B | 3,204,623 | 614,625 |
| Events in quadrant C | 3,285,861 | 589,211 |
| Events in quadrant D | 3,484,470 | 570,831 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13585 | 3 |
| B | 0 | 13856 | 2 |
| C | 0 | 14259 | 2 |
| D | 0 | 15103 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6519 | 42 | 0.644271% |
| B | 6519 | 47 | 0.720969% |
| C | 6519 | 58 | 0.889707% |
| D | 6519 | 90 | 1.380580% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7585 | 6521 | 14 | 14 | 0.18% | 0.21% |  |
| B | 7585 | 6521 | 10 | 10 | 0.13% | 0.15% |  |
| C | 7585 | 6521 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7585 | 6521 | 57 | 57 | 0.75% | 0.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 65066 | 414.5 | 776 | 761 | 155.1 |
| A | 9 | 143 | 11089 | 66.57 | 776 | 761 | 155.1 |
| A | 0 | 226 | 6752 | 38.62 | 776 | 761 | 155.1 |
| B | 5 | 236 | 28689 | 186.04 | 783 | 763 | 150.1 |
| B | 4 | 216 | 23519 | 151.6 | 783 | 763 | 150.1 |
| B | 0 | 228 | 21061 | 135.22 | 783 | 763 | 150.1 |
| C | 3 | 233 | 194194 | 1090.27 | 756 | 760 | 177.4 |
| C | 14 | 238 | 116839 | 654.27 | 756 | 760 | 177.4 |
| C | 10 | 22 | 15008 | 80.31 | 756 | 760 | 177.4 |
| D | 1 | 52 | 420444 | 2110.65 | 752 | 734 | 198.9 |
| D | 12 | 110 | 140146 | 701.08 | 752 | 734 | 198.9 |
| D | 2 | 234 | 26774 | 130.95 | 752 | 734 | 198.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
