| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_030T01_9000002326_15733cztM0_level2.evt | modeM0/AS1G08_030T01_9000002326_15733cztM0_level2_quad_clean.evt |
| Size (bytes) | 140,146,560 | 32,293,440 |
| Size | 133.7 MB | 30.8 MB |
| Events in quadrant A | 774,279 | 226,886 |
| Events in quadrant B | 785,440 | 236,305 |
| Events in quadrant C | 782,074 | 220,888 |
| Events in quadrant D | 1,797,757 | 181,958 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 30 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3196 | 1 |
| B | 0 | 3215 | 1 |
| C | 0 | 3228 | 1 |
| D | 0 | 6409 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1505 | 3 | 0.199336% |
| B | 1505 | 4 | 0.265781% |
| C | 1505 | 16 | 1.063123% |
| D | 1505 | 332 | 22.059801% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1506 | 1506 | 0 | 0 | 0.00% | 0.00% |  |
| B | 1506 | 1506 | 0 | 0 | 0.00% | 0.00% |  |
| C | 1506 | 1506 | 0 | 0 | 0.00% | 0.00% |  |
| D | 1506 | 1506 | 308 | 308 | 20.45% | 20.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 29772 | 735.7 | 193 | 189 | 40.2 |
| A | 0 | 226 | 1742 | 38.62 | 193 | 189 | 40.2 |
| A | 12 | 194 | 1379 | 29.59 | 193 | 189 | 40.2 |
| B | 0 | 230 | 4115 | 102.39 | 198 | 193 | 38.3 |
| B | 12 | 111 | 4055 | 100.82 | 198 | 193 | 38.3 |
| B | 11 | 111 | 3338 | 82.1 | 198 | 193 | 38.3 |
| C | 14 | 238 | 30643 | 665.04 | 189 | 191 | 45.8 |
| C | 3 | 233 | 8139 | 173.58 | 189 | 191 | 45.8 |
| C | 9 | 54 | 1708 | 33.13 | 189 | 191 | 45.8 |
| D | 1 | 52 | 1136303 | 27182.73 | 164 | 160 | 41.8 |
| D | 10 | 70 | 13357 | 315.74 | 164 | 160 | 41.8 |
| D | 9 | 85 | 8143 | 191.0 | 164 | 160 | 41.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
