| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_015T04_9000002328_15733cztM0_level2.evt | modeM0/AS1C03_015T04_9000002328_15733cztM0_level2_quad_clean.evt |
| Size (bytes) | 295,735,680 | 86,178,240 |
| Size | 282.0 MB | 82.2 MB |
| Events in quadrant A | 2,095,104 | 580,270 |
| Events in quadrant B | 2,101,833 | 602,502 |
| Events in quadrant C | 2,108,108 | 571,714 |
| Events in quadrant D | 2,361,370 | 556,404 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 88 | 0 |
| B | 0 | 88 | 0 |
| C | 0 | 88 | 0 |
| D | 0 | 88 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8973 | 2 |
| B | 0 | 8957 | 1 |
| C | 0 | 8963 | 1 |
| D | 0 | 9983 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4245 | 21 | 0.494700% |
| B | 4245 | 34 | 0.800942% |
| C | 4245 | 37 | 0.871614% |
| D | 4245 | 52 | 1.224971% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5561 | 4247 | 6 | 6 | 0.11% | 0.14% |  |
| B | 5561 | 4247 | 1 | 1 | 0.02% | 0.02% |  |
| C | 5561 | 4247 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5561 | 4246 | 32 | 32 | 0.58% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 69 | 65335 | 622.79 | 515 | 506 | 104.1 |
| A | 15 | 239 | 44292 | 420.63 | 515 | 506 | 104.1 |
| A | 0 | 226 | 4531 | 38.67 | 515 | 506 | 104.1 |
| B | 3 | 209 | 32304 | 322.91 | 520 | 507 | 98.5 |
| B | 4 | 173 | 10760 | 104.12 | 520 | 507 | 98.5 |
| B | 12 | 111 | 10699 | 103.5 | 520 | 507 | 98.5 |
| C | 3 | 233 | 96920 | 846.16 | 494 | 496 | 114.0 |
| C | 14 | 238 | 76995 | 671.31 | 494 | 496 | 114.0 |
| C | 10 | 22 | 5440 | 43.39 | 494 | 496 | 114.0 |
| D | 1 | 52 | 349169 | 2796.25 | 493 | 480 | 124.7 |
| D | 8 | 173 | 54820 | 435.77 | 493 | 480 | 124.7 |
| D | 8 | 174 | 23996 | 188.58 | 493 | 480 | 124.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
