| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_095T01_9000002330_15737cztM0_level2.evt | modeM0/AS1T02_095T01_9000002330_15737cztM0_level2_quad_clean.evt |
| Size (bytes) | 614,810,880 | 101,473,920 |
| Size | 586.3 MB | 96.8 MB |
| Events in quadrant A | 3,792,575 | 638,917 |
| Events in quadrant B | 4,112,008 | 653,377 |
| Events in quadrant C | 4,205,497 | 631,324 |
| Events in quadrant D | 5,962,679 | 588,795 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16701 | 3 |
| B | 0 | 17311 | 2 |
| C | 0 | 17596 | 2 |
| D | 0 | 23228 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8057 | 232 | 2.879484% |
| B | 8057 | 274 | 3.400770% |
| C | 8057 | 278 | 3.450416% |
| D | 8057 | 859 | 10.661537% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9028 | 8061 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9028 | 8061 | 3 | 3 | 0.03% | 0.04% |  |
| C | 9028 | 8061 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9028 | 8060 | 533 | 533 | 5.90% | 6.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 14085 | 66.15 | 978 | 956 | 198.5 |
| A | 13 | 210 | 12141 | 56.35 | 978 | 956 | 198.5 |
| A | 0 | 226 | 8725 | 39.14 | 978 | 956 | 198.5 |
| B | 4 | 251 | 135314 | 704.43 | 976 | 947 | 190.7 |
| B | 0 | 85 | 83173 | 431.08 | 976 | 947 | 190.7 |
| B | 12 | 111 | 22616 | 113.6 | 976 | 947 | 190.7 |
| C | 15 | 127 | 233076 | 1067.85 | 934 | 938 | 217.4 |
| C | 3 | 233 | 168668 | 771.57 | 934 | 938 | 217.4 |
| C | 14 | 238 | 144592 | 660.82 | 934 | 938 | 217.4 |
| D | 1 | 52 | 2438267 | 10943.29 | 912 | 883 | 222.7 |
| D | 2 | 234 | 31446 | 137.22 | 912 | 883 | 222.7 |
| D | 2 | 120 | 26671 | 115.78 | 912 | 883 | 222.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
