| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_100T01_9000002336_15791cztM0_level2.evt | modeM0/AS1A04_100T01_9000002336_15791cztM0_level2_quad_clean.evt |
| Size (bytes) | 442,785,600 | 107,328,960 |
| Size | 422.3 MB | 102.4 MB |
| Events in quadrant A | 3,250,298 | 693,168 |
| Events in quadrant B | 3,448,133 | 719,140 |
| Events in quadrant C | 3,195,368 | 713,422 |
| Events in quadrant D | 3,090,937 | 688,217 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13737 | 3 |
| B | 0 | 14261 | 2 |
| C | 0 | 13541 | 2 |
| D | 0 | 13441 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6254 | 81 | 1.295171% |
| B | 6254 | 102 | 1.630956% |
| C | 6254 | 88 | 1.407099% |
| D | 6254 | 65 | 1.039335% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7580 | 6256 | 27 | 27 | 0.36% | 0.43% |  |
| B | 7580 | 6256 | 15 | 15 | 0.20% | 0.24% |  |
| C | 7580 | 6256 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7580 | 6256 | 17 | 17 | 0.22% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 143555 | 902.26 | 793 | 778 | 158.2 |
| A | 14 | 254 | 35880 | 221.82 | 793 | 778 | 158.2 |
| A | 9 | 143 | 15116 | 90.61 | 793 | 778 | 158.2 |
| B | 10 | 245 | 105578 | 701.59 | 804 | 786 | 149.4 |
| B | 4 | 173 | 47124 | 310.24 | 804 | 786 | 149.4 |
| B | 7 | 220 | 30714 | 200.37 | 804 | 786 | 149.4 |
| C | 14 | 238 | 120959 | 666.56 | 784 | 792 | 180.3 |
| C | 10 | 22 | 7051 | 34.72 | 784 | 792 | 180.3 |
| C | 3 | 233 | 6137 | 29.65 | 784 | 792 | 180.3 |
| D | 1 | 52 | 68185 | 327.55 | 777 | 758 | 205.9 |
| D | 2 | 234 | 25407 | 119.74 | 777 | 758 | 205.9 |
| D | 2 | 152 | 24807 | 116.82 | 777 | 758 | 205.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
