| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_026T01_9000002342_15818cztM0_level2.evt | modeM0/AS1A04_026T01_9000002342_15818cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,388,800 | 76,962,240 |
| Size | 446.7 MB | 73.4 MB |
| Events in quadrant A | 3,156,117 | 467,488 |
| Events in quadrant B | 4,105,263 | 474,556 |
| Events in quadrant C | 3,313,526 | 476,937 |
| Events in quadrant D | 3,180,578 | 469,999 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13665 | 3 |
| B | 0 | 16598 | 2 |
| C | 0 | 14057 | 2 |
| D | 0 | 13812 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6336 | 60 | 0.946970% |
| B | 6336 | 231 | 3.645833% |
| C | 6336 | 102 | 1.609848% |
| D | 6336 | 65 | 1.025884% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7547 | 6338 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7547 | 6338 | 73 | 73 | 0.97% | 1.15% |  |
| C | 7547 | 6337 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7547 | 6338 | 11 | 11 | 0.15% | 0.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 21267 | 124.69 | 812 | 795 | 164.2 |
| A | 0 | 226 | 7223 | 39.15 | 812 | 795 | 164.2 |
| A | 12 | 194 | 6252 | 33.24 | 812 | 795 | 164.2 |
| B | 5 | 65 | 449549 | 2980.78 | 812 | 793 | 150.5 |
| B | 7 | 220 | 201805 | 1335.19 | 812 | 793 | 150.5 |
| B | 10 | 245 | 56335 | 368.93 | 812 | 793 | 150.5 |
| C | 14 | 238 | 123006 | 658.5 | 799 | 803 | 185.6 |
| C | 7 | 247 | 30663 | 160.9 | 799 | 803 | 185.6 |
| C | 3 | 233 | 29229 | 153.18 | 799 | 803 | 185.6 |
| D | 2 | 152 | 45912 | 208.97 | 802 | 788 | 215.9 |
| D | 2 | 234 | 27000 | 121.39 | 802 | 788 | 215.9 |
| D | 7 | 223 | 17364 | 76.76 | 802 | 788 | 215.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
