| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_143T01_9000002344_15854cztM0_level2.evt | modeM0/AS1A04_143T01_9000002344_15854cztM0_level2_quad_clean.evt |
| Size (bytes) | 164,338,560 | 37,733,760 |
| Size | 156.7 MB | 36.0 MB |
| Events in quadrant A | 1,058,975 | 262,102 |
| Events in quadrant B | 1,081,501 | 268,077 |
| Events in quadrant C | 1,052,728 | 251,160 |
| Events in quadrant D | 1,641,452 | 211,838 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 74 | 30 |
| B | 0 | 77 | 31 |
| C | 0 | 79 | 31 |
| D | 0 | 77 | 33 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8000 | 3499 |
| B | 0 | 7530 | 3027 |
| C | 0 | 7374 | 2981 |
| D | 0 | 10649 | 4424 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 3 |
| B | 1 | 3 | 3 |
| C | 1 | -1 | -1 |
| D | 1 | -1 | -1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2079 | 158 | 7.599808% |
| B | 2062 | 170 | 8.244423% |
| C | 2030 | 153 | 7.536946% |
| D | 1962 | 445 | 22.680938% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2942 | 2270 | 1 | 1 | 0.03% | 0.04% |  |
| B | 2929 | 2244 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2913 | 2225 | 0 | 0 | 0.00% | 0.00% |  |
| D | 2936 | 2140 | 262 | 262 | 8.92% | 12.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 11833 | 199.09 | 271 | 263 | 58.1 |
| A | 15 | 174 | 3148 | 49.64 | 271 | 263 | 58.1 |
| A | 0 | 226 | 2399 | 36.76 | 271 | 263 | 58.1 |
| B | 4 | 173 | 16997 | 301.36 | 272 | 264 | 55.5 |
| B | 12 | 111 | 6623 | 114.52 | 272 | 264 | 55.5 |
| B | 11 | 111 | 5625 | 96.55 | 272 | 264 | 55.5 |
| C | 14 | 238 | 37372 | 592.52 | 257 | 258 | 62.6 |
| C | 3 | 233 | 4447 | 66.88 | 257 | 258 | 62.6 |
| C | 13 | 61 | 1863 | 25.62 | 257 | 258 | 62.6 |
| D | 1 | 52 | 770124 | 13588.7 | 225 | 217 | 56.7 |
| D | 7 | 223 | 15321 | 266.58 | 225 | 217 | 56.7 |
| D | 2 | 234 | 6680 | 114.07 | 225 | 217 | 56.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
