| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_104T03_9000002348_15933cztM0_level2.evt | modeM0/AS1A04_104T03_9000002348_15933cztM0_level2_quad_clean.evt |
| Size (bytes) | 446,601,600 | 95,699,520 |
| Size | 425.9 MB | 91.3 MB |
| Events in quadrant A | 3,250,912 | 624,725 |
| Events in quadrant B | 3,300,463 | 632,817 |
| Events in quadrant C | 3,203,821 | 601,599 |
| Events in quadrant D | 3,336,230 | 593,540 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13985 | 3 |
| B | 0 | 13933 | 2 |
| C | 0 | 13678 | 2 |
| D | 0 | 14192 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6384 | 68 | 1.065163% |
| B | 6384 | 77 | 1.206140% |
| C | 6384 | 95 | 1.488095% |
| D | 6384 | 79 | 1.237469% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7515 | 6385 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7515 | 6385 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7515 | 6385 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7515 | 6385 | 32 | 32 | 0.43% | 0.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 80493 | 479.45 | 823 | 806 | 166.2 |
| A | 0 | 226 | 7213 | 38.55 | 823 | 806 | 166.2 |
| A | 12 | 194 | 6173 | 32.29 | 823 | 806 | 166.2 |
| B | 4 | 48 | 34892 | 218.7 | 814 | 796 | 155.9 |
| B | 4 | 216 | 22770 | 140.95 | 814 | 796 | 155.9 |
| B | 3 | 209 | 21319 | 131.64 | 814 | 796 | 155.9 |
| C | 14 | 238 | 120095 | 661.95 | 776 | 781 | 180.2 |
| C | 3 | 233 | 56485 | 309.05 | 776 | 781 | 180.2 |
| C | 13 | 61 | 5527 | 26.33 | 776 | 781 | 180.2 |
| D | 13 | 104 | 194955 | 1002.99 | 795 | 775 | 193.6 |
| D | 1 | 52 | 36962 | 186.92 | 795 | 775 | 193.6 |
| D | 13 | 172 | 29664 | 149.22 | 795 | 775 | 193.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
