| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_081T01_9000002350_15956cztM0_level2.evt | modeM0/AS1G08_081T01_9000002350_15956cztM0_level2_quad_clean.evt |
| Size (bytes) | 344,589,120 | 62,622,720 |
| Size | 328.6 MB | 59.7 MB |
| Events in quadrant A | 2,420,042 | 388,310 |
| Events in quadrant B | 2,539,145 | 392,981 |
| Events in quadrant C | 2,673,997 | 374,457 |
| Events in quadrant D | 2,446,080 | 373,869 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10764 | 1 |
| B | 0 | 10904 | 1 |
| C | 0 | 11459 | 1 |
| D | 0 | 11112 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5232 | 120 | 2.293578% |
| B | 5232 | 140 | 2.675841% |
| C | 5232 | 203 | 3.879969% |
| D | 5232 | 65 | 1.242355% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5288 | 5235 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5288 | 5235 | 1 | 1 | 0.02% | 0.02% |  |
| C | 5288 | 5235 | 34 | 34 | 0.64% | 0.65% |  |
| D | 5288 | 5235 | 1 | 1 | 0.02% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 210 | 49407 | 388.12 | 616 | 602 | 125.7 |
| A | 0 | 226 | 5429 | 38.38 | 616 | 602 | 125.7 |
| A | 12 | 194 | 4626 | 32.0 | 616 | 602 | 125.7 |
| B | 5 | 65 | 53603 | 437.68 | 617 | 600 | 121.1 |
| B | 0 | 189 | 35232 | 285.98 | 617 | 600 | 121.1 |
| B | 12 | 111 | 14316 | 113.26 | 617 | 600 | 121.1 |
| C | 9 | 236 | 223683 | 1592.88 | 591 | 595 | 140.1 |
| C | 14 | 238 | 89714 | 636.32 | 591 | 595 | 140.1 |
| C | 3 | 233 | 28048 | 196.02 | 591 | 595 | 140.1 |
| D | 12 | 227 | 119331 | 801.94 | 605 | 586 | 148.1 |
| D | 2 | 234 | 23657 | 155.81 | 605 | 586 | 148.1 |
| D | 10 | 70 | 14435 | 93.53 | 605 | 586 | 148.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
