| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_104T01_9000002356_15984cztM0_level2.evt | modeM0/AS1T02_104T01_9000002356_15984cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,482,240 | 104,365,440 |
| Size | 462.0 MB | 99.5 MB |
| Events in quadrant A | 3,388,812 | 665,976 |
| Events in quadrant B | 3,674,033 | 682,199 |
| Events in quadrant C | 3,537,448 | 657,135 |
| Events in quadrant D | 3,574,464 | 645,680 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15256 | 2 |
| B | 0 | 15859 | 2 |
| C | 0 | 15451 | 2 |
| D | 0 | 16320 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7317 | 98 | 1.339347% |
| B | 7317 | 165 | 2.255023% |
| C | 7317 | 168 | 2.296023% |
| D | 7317 | 39 | 0.533005% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7863 | 7321 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7863 | 7321 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7863 | 7321 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7863 | 7321 | 2 | 2 | 0.03% | 0.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 12819 | 67.17 | 876 | 856 | 178.1 |
| A | 0 | 226 | 7614 | 37.94 | 876 | 856 | 178.1 |
| A | 12 | 96 | 7150 | 35.34 | 876 | 856 | 178.1 |
| B | 15 | 222 | 103577 | 596.94 | 884 | 859 | 172.1 |
| B | 4 | 173 | 44797 | 255.34 | 884 | 859 | 172.1 |
| B | 12 | 111 | 20565 | 114.52 | 884 | 859 | 172.1 |
| C | 14 | 238 | 128660 | 640.46 | 849 | 851 | 199.6 |
| C | 9 | 236 | 27405 | 133.06 | 849 | 851 | 199.6 |
| C | 10 | 22 | 24517 | 118.59 | 849 | 851 | 199.6 |
| D | 12 | 110 | 301204 | 1435.1 | 856 | 829 | 209.3 |
| D | 2 | 234 | 32754 | 152.53 | 856 | 829 | 209.3 |
| D | 13 | 172 | 14733 | 66.43 | 856 | 829 | 209.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
