| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_012T01_9000002370_16046cztM0_level2.evt | modeM0/AS1G08_012T01_9000002370_16046cztM0_level2_quad_clean.evt |
| Size (bytes) | 743,889,600 | 133,634,880 |
| Size | 709.4 MB | 127.4 MB |
| Events in quadrant A | 5,434,188 | 813,083 |
| Events in quadrant B | 5,437,032 | 834,022 |
| Events in quadrant C | 5,449,445 | 807,298 |
| Events in quadrant D | 5,426,634 | 795,330 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23440 | 3 |
| B | 0 | 23526 | 2 |
| C | 0 | 23510 | 2 |
| D | 0 | 24126 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 234 | 0 |
| B | 0 | 234 | 0 |
| C | 0 | 234 | 0 |
| D | 0 | 234 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11528 | 90 | 0.780708% |
| B | 11528 | 82 | 0.711312% |
| C | 11528 | 94 | 0.815406% |
| D | 11528 | 86 | 0.746010% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13009 | 11529 | 2 | 2 | 0.02% | 0.02% |  |
| B | 13009 | 11529 | 0 | 0 | 0.00% | 0.00% |  |
| C | 13009 | 11529 | 0 | 0 | 0.00% | 0.00% |  |
| D | 13009 | 11529 | 21 | 21 | 0.16% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 80 | 126248 | 448.99 | 1373 | 1340 | 278.2 |
| A | 12 | 96 | 13788 | 44.75 | 1373 | 1340 | 278.2 |
| A | 0 | 226 | 12180 | 38.97 | 1373 | 1340 | 278.2 |
| B | 0 | 230 | 47848 | 175.82 | 1370 | 1333 | 264.6 |
| B | 12 | 111 | 32633 | 118.31 | 1370 | 1333 | 264.6 |
| B | 11 | 111 | 27828 | 100.15 | 1370 | 1333 | 264.6 |
| C | 14 | 238 | 202436 | 652.49 | 1319 | 1324 | 308.2 |
| C | 3 | 233 | 73112 | 232.91 | 1319 | 1324 | 308.2 |
| C | 8 | 128 | 11080 | 31.65 | 1319 | 1324 | 308.2 |
| D | 13 | 232 | 234480 | 716.66 | 1339 | 1301 | 325.4 |
| D | 2 | 152 | 112271 | 341.06 | 1339 | 1301 | 325.4 |
| D | 2 | 234 | 38738 | 115.06 | 1339 | 1301 | 325.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
