| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_110T01_9000002376_16084cztM0_level2.evt | modeM0/AS1T02_110T01_9000002376_16084cztM0_level2_quad_clean.evt |
| Size (bytes) | 451,549,440 | 91,877,760 |
| Size | 430.6 MB | 87.6 MB |
| Events in quadrant A | 3,206,897 | 594,427 |
| Events in quadrant B | 3,606,351 | 588,438 |
| Events in quadrant C | 3,143,376 | 566,561 |
| Events in quadrant D | 3,262,859 | 565,479 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14060 | 2 |
| B | 0 | 15067 | 1 |
| C | 0 | 13754 | 1 |
| D | 0 | 14389 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6706 | 53 | 0.790337% |
| B | 6706 | 96 | 1.431554% |
| C | 6706 | 67 | 0.999105% |
| D | 6706 | 67 | 0.999105% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7372 | 6708 | 17 | 17 | 0.23% | 0.25% |  |
| B | 7372 | 6707 | 28 | 28 | 0.38% | 0.42% |  |
| C | 7372 | 6708 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7372 | 6707 | 29 | 29 | 0.39% | 0.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 101967 | 627.96 | 796 | 779 | 161.1 |
| A | 12 | 96 | 21038 | 125.73 | 796 | 779 | 161.1 |
| A | 15 | 174 | 20588 | 122.93 | 796 | 779 | 161.1 |
| B | 0 | 189 | 110925 | 728.97 | 795 | 774 | 151.1 |
| B | 0 | 190 | 96960 | 636.55 | 795 | 774 | 151.1 |
| B | 7 | 220 | 95204 | 624.93 | 795 | 774 | 151.1 |
| C | 14 | 238 | 117379 | 651.18 | 766 | 771 | 179.1 |
| C | 0 | 207 | 20844 | 112.1 | 766 | 771 | 179.1 |
| C | 3 | 233 | 13530 | 71.25 | 766 | 771 | 179.1 |
| D | 12 | 218 | 164107 | 861.63 | 777 | 754 | 189.6 |
| D | 2 | 33 | 60644 | 315.9 | 777 | 754 | 189.6 |
| D | 7 | 38 | 41831 | 216.67 | 777 | 754 | 189.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
