| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_110T01_9000002376_16096cztM0_level2.evt | modeM0/AS1T02_110T01_9000002376_16096cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,049,600 | 88,073,280 |
| Size | 436.8 MB | 84.0 MB |
| Events in quadrant A | 3,054,969 | 586,681 |
| Events in quadrant B | 3,660,458 | 576,515 |
| Events in quadrant C | 3,040,444 | 546,749 |
| Events in quadrant D | 3,708,410 | 537,885 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12784 | 2 |
| B | 0 | 14680 | 1 |
| C | 0 | 12572 | 1 |
| D | 0 | 14874 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5996 | 103 | 1.717812% |
| B | 5996 | 145 | 2.418279% |
| C | 5996 | 125 | 2.084723% |
| D | 5996 | 261 | 4.352902% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7262 | 5997 | 7 | 7 | 0.10% | 0.12% |  |
| B | 7262 | 5997 | 49 | 49 | 0.67% | 0.82% |  |
| C | 7262 | 5997 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7261 | 5996 | 189 | 189 | 2.60% | 3.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 41450 | 264.75 | 764 | 749 | 153.7 |
| A | 15 | 174 | 31729 | 201.52 | 764 | 749 | 153.7 |
| A | 13 | 248 | 27940 | 176.87 | 764 | 749 | 153.7 |
| B | 4 | 173 | 216324 | 1529.67 | 756 | 738 | 140.9 |
| B | 7 | 220 | 190294 | 1344.97 | 756 | 738 | 140.9 |
| B | 0 | 189 | 159445 | 1126.09 | 756 | 738 | 140.9 |
| C | 14 | 238 | 110760 | 652.2 | 726 | 731 | 168.7 |
| C | 3 | 233 | 77360 | 454.22 | 726 | 731 | 168.7 |
| C | 0 | 207 | 15866 | 89.71 | 726 | 731 | 168.7 |
| D | 7 | 38 | 414322 | 2310.73 | 740 | 719 | 179.0 |
| D | 12 | 218 | 314654 | 1753.9 | 740 | 719 | 179.0 |
| D | 1 | 52 | 98049 | 543.77 | 740 | 719 | 179.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
