| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_209T01_9000002378_16107cztM0_level2.evt | modeM0/AS1A04_209T01_9000002378_16107cztM0_level2_quad_clean.evt |
| Size (bytes) | 434,998,080 | 69,805,440 |
| Size | 414.8 MB | 66.6 MB |
| Events in quadrant A | 3,132,013 | 426,985 |
| Events in quadrant B | 3,197,027 | 430,335 |
| Events in quadrant C | 3,338,670 | 407,010 |
| Events in quadrant D | 3,079,084 | 410,712 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13158 | 2 |
| B | 0 | 13234 | 1 |
| C | 0 | 13728 | 1 |
| D | 0 | 13156 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6282 | 77 | 1.225724% |
| B | 6282 | 78 | 1.241643% |
| C | 6282 | 116 | 1.846546% |
| D | 6282 | 55 | 0.875517% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7383 | 6283 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7383 | 6283 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7383 | 6283 | 27 | 27 | 0.37% | 0.43% |  |
| D | 7383 | 6283 | 2 | 2 | 0.03% | 0.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7160 | 39.02 | 812 | 796 | 163.1 |
| A | 12 | 194 | 6151 | 32.83 | 812 | 796 | 163.1 |
| A | 3 | 137 | 5352 | 27.93 | 812 | 796 | 163.1 |
| B | 0 | 189 | 29494 | 185.82 | 802 | 784 | 154.5 |
| B | 4 | 173 | 18571 | 115.12 | 802 | 784 | 154.5 |
| B | 12 | 111 | 17773 | 109.96 | 802 | 784 | 154.5 |
| C | 9 | 236 | 199677 | 1122.07 | 765 | 771 | 177.3 |
| C | 14 | 238 | 118077 | 661.75 | 765 | 771 | 177.3 |
| C | 3 | 233 | 30498 | 167.7 | 765 | 771 | 177.3 |
| D | 5 | 222 | 49461 | 251.94 | 791 | 770 | 193.3 |
| D | 2 | 234 | 24546 | 123.02 | 791 | 770 | 193.3 |
| D | 13 | 112 | 20231 | 100.7 | 791 | 770 | 193.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
