| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_094T01_9000002380_16119cztM0_level2.evt | modeM0/AS1T02_094T01_9000002380_16119cztM0_level2_quad_clean.evt |
| Size (bytes) | 608,425,920 | 83,226,240 |
| Size | 580.2 MB | 79.4 MB |
| Events in quadrant A | 3,727,930 | 527,251 |
| Events in quadrant B | 3,658,408 | 530,954 |
| Events in quadrant C | 3,578,693 | 508,510 |
| Events in quadrant D | 6,976,570 | 455,173 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15547 | 3 |
| B | 0 | 15174 | 2 |
| C | 0 | 15068 | 2 |
| D | 0 | 25544 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7148 | 154 | 2.154449% |
| B | 7148 | 148 | 2.070509% |
| C | 7148 | 169 | 2.364298% |
| D | 7148 | 877 | 12.269166% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8859 | 7149 | 30 | 30 | 0.34% | 0.42% |  |
| B | 8859 | 7149 | 3 | 3 | 0.03% | 0.04% |  |
| C | 8859 | 7149 | 20 | 20 | 0.23% | 0.28% |  |
| D | 8859 | 7149 | 784 | 784 | 8.85% | 10.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 263758 | 1456.23 | 889 | 869 | 180.5 |
| A | 13 | 248 | 18099 | 95.44 | 889 | 869 | 180.5 |
| A | 8 | 247 | 17479 | 92.01 | 889 | 869 | 180.5 |
| B | 0 | 189 | 59924 | 346.78 | 889 | 868 | 170.3 |
| B | 4 | 48 | 31605 | 180.49 | 889 | 868 | 170.3 |
| B | 4 | 216 | 27285 | 155.12 | 889 | 868 | 170.3 |
| C | 14 | 238 | 129204 | 645.94 | 850 | 857 | 198.7 |
| C | 9 | 236 | 104335 | 520.78 | 850 | 857 | 198.7 |
| C | 3 | 233 | 26538 | 129.25 | 850 | 857 | 198.7 |
| D | 5 | 222 | 1626321 | 8007.07 | 827 | 800 | 203.0 |
| D | 1 | 52 | 1517409 | 7470.59 | 827 | 800 | 203.0 |
| D | 7 | 38 | 661316 | 3253.6 | 827 | 800 | 203.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
