| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_092T01_9000002384_16132cztM0_level2.evt | modeM0/AS1T02_092T01_9000002384_16132cztM0_level2_quad_clean.evt |
| Size (bytes) | 853,174,080 | 131,186,880 |
| Size | 813.7 MB | 125.1 MB |
| Events in quadrant A | 6,487,590 | 794,085 |
| Events in quadrant B | 6,927,666 | 797,886 |
| Events in quadrant C | 5,740,843 | 771,921 |
| Events in quadrant D | 5,861,283 | 770,166 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 246 | 0 |
| B | 0 | 246 | 0 |
| C | 0 | 246 | 0 |
| D | 0 | 246 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27496 | 3 |
| B | 0 | 28676 | 2 |
| C | 0 | 24790 | 2 |
| D | 0 | 25862 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12131 | 322 | 2.654357% |
| B | 12131 | 231 | 1.904212% |
| C | 12131 | 125 | 1.030418% |
| D | 12131 | 125 | 1.030418% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13416 | 12131 | 164 | 164 | 1.22% | 1.35% |  |
| B | 13416 | 12132 | 72 | 72 | 0.54% | 0.59% |  |
| C | 13416 | 12132 | 0 | 0 | 0.00% | 0.00% |  |
| D | 13416 | 12132 | 63 | 63 | 0.47% | 0.52% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 844270 | 2920.93 | 1430 | 1398 | 288.6 |
| A | 0 | 253 | 71687 | 243.58 | 1430 | 1398 | 288.6 |
| A | 15 | 223 | 34551 | 114.89 | 1430 | 1398 | 288.6 |
| B | 5 | 65 | 800180 | 2866.8 | 1437 | 1397 | 278.6 |
| B | 4 | 216 | 122676 | 435.27 | 1437 | 1397 | 278.6 |
| B | 0 | 189 | 105262 | 372.77 | 1437 | 1397 | 278.6 |
| C | 14 | 238 | 212474 | 648.67 | 1382 | 1392 | 325.4 |
| C | 3 | 9 | 73104 | 220.38 | 1382 | 1392 | 325.4 |
| C | 3 | 233 | 43713 | 130.06 | 1382 | 1392 | 325.4 |
| D | 1 | 52 | 438946 | 1276.82 | 1401 | 1361 | 342.7 |
| D | 2 | 234 | 53433 | 151.94 | 1401 | 1361 | 342.7 |
| D | 13 | 112 | 39521 | 111.35 | 1401 | 1361 | 342.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
