| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_109T01_9000002386_16155cztM0_level2.evt | modeM0/AS1T02_109T01_9000002386_16155cztM0_level2_quad_clean.evt |
| Size (bytes) | 541,111,680 | 69,269,760 |
| Size | 516.0 MB | 66.1 MB |
| Events in quadrant A | 3,404,331 | 415,850 |
| Events in quadrant B | 3,532,415 | 424,556 |
| Events in quadrant C | 3,437,895 | 407,178 |
| Events in quadrant D | 5,572,748 | 396,993 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14051 | 2 |
| B | 0 | 14447 | 1 |
| C | 0 | 14024 | 1 |
| D | 0 | 20950 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6491 | 127 | 1.956555% |
| B | 6491 | 115 | 1.771684% |
| C | 6491 | 125 | 1.925743% |
| D | 6491 | 550 | 8.473271% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7572 | 6493 | 24 | 24 | 0.32% | 0.37% |  |
| B | 7572 | 6493 | 10 | 10 | 0.13% | 0.15% |  |
| C | 7572 | 6493 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7572 | 6493 | 445 | 445 | 5.88% | 6.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 146008 | 848.11 | 841 | 826 | 171.2 |
| A | 8 | 247 | 14457 | 79.63 | 841 | 826 | 171.2 |
| A | 15 | 239 | 8441 | 44.48 | 841 | 826 | 171.2 |
| B | 5 | 65 | 106528 | 664.64 | 837 | 821 | 159.0 |
| B | 4 | 216 | 40477 | 249.34 | 837 | 821 | 159.0 |
| B | 3 | 209 | 27288 | 166.41 | 837 | 821 | 159.0 |
| C | 3 | 233 | 127555 | 671.54 | 806 | 811 | 188.7 |
| C | 14 | 238 | 125355 | 659.89 | 806 | 811 | 188.7 |
| C | 0 | 207 | 36247 | 187.76 | 806 | 811 | 188.7 |
| D | 1 | 52 | 2086085 | 10588.12 | 805 | 780 | 196.9 |
| D | 7 | 38 | 189372 | 957.57 | 805 | 780 | 196.9 |
| D | 5 | 222 | 125666 | 634.11 | 805 | 780 | 196.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
