| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_112T01_9000002390_16264cztM0_level2.evt | modeM0/AS1T02_112T01_9000002390_16264cztM0_level2_quad_clean.evt |
| Size (bytes) | 458,156,160 | 52,107,840 |
| Size | 436.9 MB | 49.7 MB |
| Events in quadrant A | 3,905,107 | 313,021 |
| Events in quadrant B | 2,601,231 | 327,451 |
| Events in quadrant C | 2,174,944 | 323,198 |
| Events in quadrant D | 4,881,419 | 290,038 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94 | 0 |
| B | 0 | 94 | 0 |
| C | 0 | 94 | 0 |
| D | 0 | 94 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14661 | 1 |
| B | 0 | 10589 | 1 |
| C | 0 | 9412 | 1 |
| D | 0 | 17627 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4603 | 512 | 11.123181% |
| B | 4603 | 43 | 0.934173% |
| C | 4603 | 26 | 0.564849% |
| D | 4603 | 851 | 18.487943% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5479 | 4605 | 330 | 330 | 6.02% | 7.17% |  |
| B | 5479 | 4605 | 19 | 19 | 0.35% | 0.41% |  |
| C | 5479 | 4605 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5479 | 4605 | 683 | 683 | 12.47% | 14.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 1759073 | 16139.69 | 531 | 519 | 109.0 |
| A | 9 | 143 | 76573 | 698.01 | 531 | 519 | 109.0 |
| A | 14 | 4 | 19163 | 171.11 | 531 | 519 | 109.0 |
| B | 3 | 112 | 240867 | 2256.96 | 547 | 534 | 106.5 |
| B | 7 | 220 | 43734 | 405.69 | 547 | 534 | 106.5 |
| B | 3 | 209 | 38023 | 352.06 | 547 | 534 | 106.5 |
| C | 14 | 238 | 81387 | 654.22 | 526 | 531 | 123.6 |
| C | 3 | 233 | 24929 | 197.41 | 526 | 531 | 123.6 |
| C | 0 | 207 | 12020 | 92.96 | 526 | 531 | 123.6 |
| D | 1 | 52 | 2949051 | 24672.93 | 487 | 473 | 119.5 |
| D | 15 | 0 | 56867 | 471.89 | 487 | 473 | 119.5 |
| D | 10 | 70 | 22051 | 180.56 | 487 | 473 | 119.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
