| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_072T05_9000002394_16277cztM0_level2.evt | modeM0/AS1A05_072T05_9000002394_16277cztM0_level2_quad_clean.evt |
| Size (bytes) | 873,887,040 | 168,966,720 |
| Size | 833.4 MB | 161.1 MB |
| Events in quadrant A | 6,172,338 | 1,058,195 |
| Events in quadrant B | 6,426,481 | 1,082,284 |
| Events in quadrant C | 6,260,785 | 1,061,840 |
| Events in quadrant D | 6,737,274 | 1,028,168 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 262 | 0 |
| B | 0 | 262 | 0 |
| C | 0 | 262 | 0 |
| D | 0 | 262 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27144 | 4 |
| B | 0 | 27401 | 3 |
| C | 0 | 27013 | 3 |
| D | 0 | 28947 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12834 | 112 | 0.872682% |
| B | 12834 | 94 | 0.732429% |
| C | 12834 | 115 | 0.896057% |
| D | 12834 | 201 | 1.566152% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14615 | 12838 | 45 | 45 | 0.31% | 0.35% |  |
| B | 14615 | 12838 | 8 | 8 | 0.05% | 0.06% |  |
| C | 14615 | 12838 | 0 | 0 | 0.00% | 0.00% |  |
| D | 14615 | 12838 | 127 | 127 | 0.87% | 0.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 261986 | 846.09 | 1515 | 1479 | 307.9 |
| A | 15 | 239 | 76189 | 242.65 | 1515 | 1479 | 307.9 |
| A | 14 | 4 | 15321 | 44.96 | 1515 | 1479 | 307.9 |
| B | 0 | 198 | 84040 | 279.08 | 1527 | 1484 | 295.8 |
| B | 0 | 189 | 78586 | 260.64 | 1527 | 1484 | 295.8 |
| B | 0 | 219 | 64676 | 213.62 | 1527 | 1484 | 295.8 |
| C | 3 | 233 | 284407 | 830.06 | 1461 | 1469 | 340.9 |
| C | 14 | 238 | 222560 | 648.62 | 1461 | 1469 | 340.9 |
| C | 0 | 207 | 60665 | 173.66 | 1461 | 1469 | 340.9 |
| D | 1 | 52 | 952587 | 2656.83 | 1468 | 1424 | 358.0 |
| D | 10 | 70 | 150356 | 416.0 | 1468 | 1424 | 358.0 |
| D | 2 | 234 | 48816 | 132.38 | 1468 | 1424 | 358.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
