| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_101T01_9000002412_16343cztM0_level2.evt | modeM0/AS1A05_101T01_9000002412_16343cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,476,160 | 73,134,720 |
| Size | 484.0 MB | 69.7 MB |
| Events in quadrant A | 3,284,647 | 439,784 |
| Events in quadrant B | 4,614,423 | 440,045 |
| Events in quadrant C | 3,411,076 | 447,943 |
| Events in quadrant D | 3,623,391 | 439,105 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13493 | 3 |
| B | 0 | 17825 | 2 |
| C | 0 | 14036 | 2 |
| D | 0 | 14724 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6414 | 121 | 1.886498% |
| B | 6414 | 451 | 7.031494% |
| C | 6414 | 190 | 2.962270% |
| D | 6414 | 162 | 2.525725% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7585 | 6415 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7585 | 6415 | 157 | 157 | 2.07% | 2.45% |  |
| C | 7585 | 6415 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7585 | 6415 | 35 | 35 | 0.46% | 0.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 15229 | 86.23 | 844 | 827 | 167.0 |
| A | 15 | 174 | 14611 | 82.53 | 844 | 827 | 167.0 |
| A | 0 | 226 | 7513 | 40.03 | 844 | 827 | 167.0 |
| B | 3 | 112 | 1083641 | 7002.85 | 829 | 810 | 154.6 |
| B | 3 | 64 | 68568 | 438.2 | 829 | 810 | 154.6 |
| B | 15 | 35 | 65788 | 420.22 | 829 | 810 | 154.6 |
| C | 14 | 238 | 128807 | 685.22 | 824 | 832 | 186.8 |
| C | 3 | 233 | 70250 | 371.69 | 824 | 832 | 186.8 |
| C | 13 | 61 | 5715 | 26.15 | 824 | 832 | 186.8 |
| D | 12 | 218 | 378568 | 1871.98 | 835 | 810 | 201.8 |
| D | 2 | 234 | 23014 | 110.03 | 835 | 810 | 201.8 |
| D | 2 | 122 | 18698 | 88.64 | 835 | 810 | 201.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
