| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T04_9000002418_16367cztM0_level2.evt | modeM0/AS1A05_069T04_9000002418_16367cztM0_level2_quad_clean.evt |
| Size (bytes) | 312,431,040 | 54,308,160 |
| Size | 298.0 MB | 51.8 MB |
| Events in quadrant A | 2,170,443 | 337,742 |
| Events in quadrant B | 2,478,837 | 346,178 |
| Events in quadrant C | 2,280,723 | 326,547 |
| Events in quadrant D | 2,222,738 | 315,048 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9439 | 2 |
| B | 0 | 10293 | 1 |
| C | 0 | 9648 | 1 |
| D | 0 | 9538 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 92 | 0 |
| B | 0 | 92 | 0 |
| C | 0 | 92 | 0 |
| D | 0 | 92 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4529 | 21 | 0.463679% |
| B | 4529 | 39 | 0.861117% |
| C | 4529 | 52 | 1.148156% |
| D | 4529 | 20 | 0.441599% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5620 | 4531 | 7 | 7 | 0.12% | 0.15% |  |
| B | 5620 | 4531 | 11 | 11 | 0.20% | 0.24% |  |
| C | 5620 | 4531 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5620 | 4531 | 6 | 6 | 0.11% | 0.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 50509 | 450.96 | 548 | 536 | 110.8 |
| A | 9 | 143 | 6441 | 53.29 | 548 | 536 | 110.8 |
| A | 0 | 226 | 4806 | 38.53 | 548 | 536 | 110.8 |
| B | 10 | 16 | 91473 | 853.27 | 553 | 538 | 106.6 |
| B | 15 | 35 | 77347 | 720.72 | 553 | 538 | 106.6 |
| B | 4 | 173 | 40654 | 376.42 | 553 | 538 | 106.6 |
| C | 3 | 233 | 129482 | 1045.58 | 528 | 533 | 123.3 |
| C | 14 | 238 | 82993 | 668.63 | 528 | 533 | 123.3 |
| C | 10 | 169 | 6381 | 47.42 | 528 | 533 | 123.3 |
| D | 2 | 122 | 70193 | 539.0 | 531 | 517 | 129.3 |
| D | 1 | 52 | 60760 | 466.03 | 531 | 517 | 129.3 |
| D | 12 | 218 | 47067 | 360.1 | 531 | 517 | 129.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
