| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T04_9000002418_16369cztM0_level2.evt | modeM0/AS1A05_069T04_9000002418_16369cztM0_level2_quad_clean.evt |
| Size (bytes) | 504,414,720 | 80,726,400 |
| Size | 481.0 MB | 77.0 MB |
| Events in quadrant A | 3,627,613 | 499,407 |
| Events in quadrant B | 3,850,982 | 534,559 |
| Events in quadrant C | 3,494,646 | 501,512 |
| Events in quadrant D | 3,881,318 | 474,791 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14633 | 3 |
| B | 0 | 15451 | 2 |
| C | 0 | 14335 | 2 |
| D | 0 | 15670 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6221 | 243 | 3.906124% |
| B | 6221 | 103 | 1.655682% |
| C | 6221 | 102 | 1.639608% |
| D | 6221 | 132 | 2.121845% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7542 | 6222 | 186 | 186 | 2.47% | 2.99% |  |
| B | 7542 | 6223 | 29 | 29 | 0.38% | 0.47% |  |
| C | 7542 | 6223 | 7 | 7 | 0.09% | 0.11% |  |
| D | 7542 | 6223 | 104 | 104 | 1.38% | 1.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 613316 | 3966.11 | 775 | 761 | 154.4 |
| A | 15 | 223 | 19409 | 120.74 | 775 | 761 | 154.4 |
| A | 15 | 239 | 7991 | 46.81 | 775 | 761 | 154.4 |
| B | 10 | 16 | 259252 | 1723.3 | 802 | 782 | 150.0 |
| B | 15 | 35 | 153342 | 1017.16 | 802 | 782 | 150.0 |
| B | 4 | 173 | 99992 | 661.46 | 802 | 782 | 150.0 |
| C | 3 | 233 | 388899 | 2194.68 | 764 | 770 | 176.8 |
| C | 14 | 238 | 118903 | 667.98 | 764 | 770 | 176.8 |
| C | 13 | 61 | 5299 | 25.61 | 764 | 770 | 176.8 |
| D | 12 | 218 | 493080 | 2649.62 | 760 | 740 | 185.8 |
| D | 1 | 52 | 395481 | 2124.37 | 760 | 740 | 185.8 |
| D | 13 | 112 | 51855 | 275.09 | 760 | 740 | 185.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
