| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T04_9000002418_16371cztM0_level2.evt | modeM0/AS1A05_069T04_9000002418_16371cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,050,240 | 66,277,440 |
| Size | 461.6 MB | 63.2 MB |
| Events in quadrant A | 3,336,221 | 400,062 |
| Events in quadrant B | 3,819,180 | 407,218 |
| Events in quadrant C | 3,818,436 | 380,818 |
| Events in quadrant D | 3,253,092 | 373,718 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13605 | 3 |
| B | 0 | 15140 | 2 |
| C | 0 | 15326 | 2 |
| D | 0 | 13656 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6372 | 65 | 1.020088% |
| B | 6372 | 140 | 2.197112% |
| C | 6372 | 96 | 1.506591% |
| D | 6372 | 58 | 0.910232% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7713 | 6375 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7713 | 6375 | 27 | 27 | 0.35% | 0.42% |  |
| C | 7713 | 6375 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7713 | 6375 | 29 | 29 | 0.38% | 0.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 51584 | 303.63 | 844 | 829 | 167.2 |
| A | 15 | 223 | 20079 | 115.16 | 844 | 829 | 167.2 |
| A | 15 | 239 | 11407 | 63.28 | 844 | 829 | 167.2 |
| B | 0 | 85 | 152717 | 953.58 | 851 | 832 | 159.3 |
| B | 10 | 16 | 114516 | 713.74 | 851 | 832 | 159.3 |
| B | 4 | 173 | 87706 | 545.42 | 851 | 832 | 159.3 |
| C | 3 | 233 | 566458 | 3055.72 | 800 | 807 | 185.1 |
| C | 14 | 238 | 126654 | 679.84 | 800 | 807 | 185.1 |
| C | 13 | 61 | 5695 | 26.41 | 800 | 807 | 185.1 |
| D | 10 | 70 | 103542 | 524.23 | 807 | 783 | 196.0 |
| D | 7 | 223 | 28121 | 139.47 | 807 | 783 | 196.0 |
| D | 2 | 234 | 23451 | 115.64 | 807 | 783 | 196.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
