| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T05_9000002420_16382cztM0_level2.evt | modeM0/AS1A05_069T05_9000002420_16382cztM0_level2_quad_clean.evt |
| Size (bytes) | 447,269,760 | 90,354,240 |
| Size | 426.5 MB | 86.2 MB |
| Events in quadrant A | 3,074,033 | 584,426 |
| Events in quadrant B | 3,636,587 | 599,268 |
| Events in quadrant C | 3,125,005 | 569,284 |
| Events in quadrant D | 3,276,909 | 538,572 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13355 | 3 |
| B | 0 | 14834 | 2 |
| C | 0 | 13307 | 2 |
| D | 0 | 14058 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6370 | 17 | 0.266876% |
| B | 6370 | 72 | 1.130298% |
| C | 6370 | 42 | 0.659341% |
| D | 6370 | 97 | 1.522763% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7521 | 6372 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7521 | 6372 | 37 | 37 | 0.49% | 0.58% |  |
| C | 7521 | 6372 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7521 | 6372 | 57 | 57 | 0.76% | 0.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 82740 | 532.61 | 770 | 753 | 153.9 |
| A | 9 | 143 | 14261 | 87.75 | 770 | 753 | 153.9 |
| A | 3 | 1 | 9559 | 57.21 | 770 | 753 | 153.9 |
| B | 10 | 16 | 257873 | 1739.19 | 778 | 758 | 147.8 |
| B | 15 | 35 | 132333 | 890.01 | 778 | 758 | 147.8 |
| B | 0 | 189 | 91989 | 617.11 | 778 | 758 | 147.8 |
| C | 14 | 238 | 115443 | 658.87 | 745 | 749 | 174.1 |
| C | 3 | 233 | 93463 | 532.61 | 745 | 749 | 174.1 |
| C | 10 | 169 | 10719 | 57.27 | 745 | 749 | 174.1 |
| D | 10 | 70 | 132050 | 721.02 | 741 | 720 | 182.1 |
| D | 12 | 218 | 110957 | 605.22 | 741 | 720 | 182.1 |
| D | 12 | 110 | 101685 | 554.31 | 741 | 720 | 182.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
