| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T04_9000002428_16437cztM0_level2.evt | modeM0/AS1A05_069T04_9000002428_16437cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,385,280 | 90,881,280 |
| Size | 482.0 MB | 86.7 MB |
| Events in quadrant A | 3,211,288 | 583,006 |
| Events in quadrant B | 3,581,747 | 591,381 |
| Events in quadrant C | 3,960,882 | 562,549 |
| Events in quadrant D | 4,091,279 | 542,468 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14054 | 2 |
| B | 0 | 14915 | 1 |
| C | 0 | 16123 | 1 |
| D | 0 | 16694 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6782 | 40 | 0.589797% |
| B | 6782 | 79 | 1.164848% |
| C | 6782 | 136 | 2.005308% |
| D | 6782 | 156 | 2.300206% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7648 | 6784 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7648 | 6784 | 15 | 15 | 0.20% | 0.22% |  |
| C | 7648 | 6784 | 30 | 30 | 0.39% | 0.44% |  |
| D | 7648 | 6784 | 121 | 121 | 1.58% | 1.78% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 57364 | 346.07 | 811 | 794 | 163.5 |
| A | 3 | 1 | 34005 | 203.17 | 811 | 794 | 163.5 |
| A | 0 | 226 | 7253 | 39.51 | 811 | 794 | 163.5 |
| B | 15 | 35 | 90234 | 570.94 | 810 | 789 | 156.7 |
| B | 0 | 198 | 78113 | 493.57 | 810 | 789 | 156.7 |
| B | 3 | 209 | 60810 | 383.12 | 810 | 789 | 156.7 |
| C | 3 | 233 | 479864 | 2629.83 | 774 | 778 | 182.2 |
| C | 4 | 254 | 319056 | 1747.11 | 774 | 778 | 182.2 |
| C | 14 | 238 | 117627 | 641.41 | 774 | 778 | 182.2 |
| D | 1 | 52 | 593028 | 3077.28 | 783 | 757 | 192.5 |
| D | 5 | 222 | 239926 | 1242.66 | 783 | 757 | 192.5 |
| D | 12 | 218 | 154529 | 798.96 | 783 | 757 | 192.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
