| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_069T04_9000002428_16445cztM0_level2.evt | modeM0/AS1A05_069T04_9000002428_16445cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,248,320 | 68,497,920 |
| Size | 514.3 MB | 65.3 MB |
| Events in quadrant A | 3,448,030 | 411,387 |
| Events in quadrant B | 3,625,079 | 421,352 |
| Events in quadrant C | 5,353,993 | 379,114 |
| Events in quadrant D | 3,441,792 | 386,989 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14492 | 3 |
| B | 0 | 14961 | 2 |
| C | 0 | 20493 | 2 |
| D | 0 | 14778 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6810 | 73 | 1.071953% |
| B | 6810 | 121 | 1.776799% |
| C | 6810 | 531 | 7.797357% |
| D | 6810 | 50 | 0.734214% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7796 | 6811 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7796 | 6811 | 8 | 8 | 0.10% | 0.12% |  |
| C | 7796 | 6811 | 322 | 322 | 4.13% | 4.73% |  |
| D | 7796 | 6812 | 18 | 18 | 0.23% | 0.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 200540 | 1179.38 | 841 | 823 | 169.3 |
| A | 4 | 208 | 9648 | 52.11 | 841 | 823 | 169.3 |
| A | 0 | 226 | 7448 | 39.12 | 841 | 823 | 169.3 |
| B | 15 | 35 | 137247 | 837.39 | 848 | 825 | 162.9 |
| B | 4 | 173 | 46924 | 282.97 | 848 | 825 | 162.9 |
| B | 0 | 198 | 43897 | 264.39 | 848 | 825 | 162.9 |
| C | 4 | 254 | 1588854 | 8628.73 | 785 | 790 | 184.0 |
| C | 3 | 233 | 543377 | 2948.14 | 785 | 790 | 184.0 |
| C | 14 | 238 | 121990 | 658.54 | 785 | 790 | 184.0 |
| D | 12 | 110 | 263510 | 1328.53 | 811 | 789 | 197.8 |
| D | 5 | 222 | 67219 | 335.93 | 811 | 789 | 197.8 |
| D | 2 | 234 | 23995 | 117.35 | 811 | 789 | 197.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
