| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_008T01_9000002434_16471cztM0_level2.evt | modeM0/AS1C04_008T01_9000002434_16471cztM0_level2_quad_clean.evt |
| Size (bytes) | 424,837,440 | 97,176,960 |
| Size | 405.2 MB | 92.7 MB |
| Events in quadrant A | 3,297,580 | 642,035 |
| Events in quadrant B | 3,427,884 | 673,845 |
| Events in quadrant C | 3,103,757 | 637,446 |
| Events in quadrant D | 2,671,625 | 613,189 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13218 | 1 |
| B | 0 | 13731 | 1 |
| C | 0 | 12774 | 1 |
| D | 0 | 11457 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 110 | 0 |
| B | 0 | 110 | 0 |
| C | 0 | 110 | 0 |
| D | 0 | 110 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5376 | 172 | 3.199405% |
| B | 5376 | 131 | 2.436756% |
| C | 5376 | 110 | 2.046131% |
| D | 5376 | 24 | 0.446429% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6667 | 5377 | 99 | 99 | 1.48% | 1.84% |  |
| B | 6667 | 5377 | 33 | 33 | 0.49% | 0.61% |  |
| C | 6667 | 5377 | 6 | 6 | 0.09% | 0.11% |  |
| D | 6667 | 5377 | 6 | 6 | 0.09% | 0.11% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 628527 | 4455.72 | 695 | 686 | 140.9 |
| A | 0 | 226 | 6094 | 38.38 | 695 | 686 | 140.9 |
| A | 12 | 194 | 5019 | 30.75 | 695 | 686 | 140.9 |
| B | 4 | 173 | 317187 | 2344.64 | 709 | 696 | 135.0 |
| B | 3 | 209 | 95678 | 703.65 | 709 | 696 | 135.0 |
| B | 15 | 35 | 87208 | 640.9 | 709 | 696 | 135.0 |
| C | 3 | 233 | 308105 | 1944.66 | 678 | 686 | 158.1 |
| C | 14 | 238 | 105660 | 664.04 | 678 | 686 | 158.1 |
| C | 7 | 247 | 43280 | 269.44 | 678 | 686 | 158.1 |
| D | 2 | 120 | 30119 | 178.46 | 678 | 660 | 165.1 |
| D | 2 | 234 | 22655 | 133.24 | 678 | 660 | 165.1 |
| D | 13 | 248 | 21870 | 128.48 | 678 | 660 | 165.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
