| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000002440_16495cztM0_level2.evt | modeM0/AS1A05_174T01_9000002440_16495cztM0_level2_quad_clean.evt |
| Size (bytes) | 568,180,800 | 92,620,800 |
| Size | 541.9 MB | 88.3 MB |
| Events in quadrant A | 3,800,752 | 589,373 |
| Events in quadrant B | 3,467,848 | 602,785 |
| Events in quadrant C | 5,824,542 | 566,822 |
| Events in quadrant D | 3,648,248 | 567,004 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15892 | 3 |
| B | 0 | 14584 | 2 |
| C | 0 | 22258 | 2 |
| D | 0 | 15604 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6880 | 213 | 3.095930% |
| B | 6880 | 143 | 2.078488% |
| C | 6880 | 539 | 7.834302% |
| D | 6880 | 162 | 2.354651% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8461 | 6881 | 61 | 61 | 0.72% | 0.89% |  |
| B | 8461 | 6881 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8461 | 6881 | 30 | 30 | 0.35% | 0.44% |  |
| D | 8461 | 6881 | 40 | 40 | 0.47% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 579306 | 3408.95 | 837 | 819 | 169.7 |
| A | 0 | 226 | 7460 | 39.13 | 837 | 819 | 169.7 |
| A | 3 | 137 | 6314 | 32.38 | 837 | 819 | 169.7 |
| B | 15 | 35 | 52662 | 318.24 | 837 | 816 | 162.9 |
| B | 4 | 48 | 39232 | 235.8 | 837 | 816 | 162.9 |
| B | 4 | 216 | 22160 | 131.01 | 837 | 816 | 162.9 |
| C | 3 | 233 | 2633316 | 14312.3 | 780 | 786 | 183.9 |
| C | 14 | 238 | 119232 | 643.96 | 780 | 786 | 183.9 |
| C | 7 | 247 | 32376 | 171.75 | 780 | 786 | 183.9 |
| D | 5 | 222 | 162003 | 814.36 | 811 | 786 | 198.0 |
| D | 12 | 218 | 147277 | 739.97 | 811 | 786 | 198.0 |
| D | 1 | 52 | 86161 | 431.25 | 811 | 786 | 198.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
