| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000002440_16499cztM0_level2.evt | modeM0/AS1A05_174T01_9000002440_16499cztM0_level2_quad_clean.evt |
| Size (bytes) | 521,282,880 | 93,732,480 |
| Size | 497.1 MB | 89.4 MB |
| Events in quadrant A | 3,447,725 | 607,715 |
| Events in quadrant B | 3,303,964 | 632,999 |
| Events in quadrant C | 4,730,196 | 584,250 |
| Events in quadrant D | 3,874,124 | 569,884 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14369 | 3 |
| B | 0 | 13923 | 2 |
| C | 0 | 18436 | 2 |
| D | 0 | 15622 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6357 | 59 | 0.928111% |
| B | 6357 | 46 | 0.723612% |
| C | 6357 | 197 | 3.098946% |
| D | 6357 | 77 | 1.211263% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7623 | 6359 | 29 | 29 | 0.38% | 0.46% |  |
| B | 7623 | 6358 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7623 | 6359 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7623 | 6359 | 59 | 59 | 0.77% | 0.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 395265 | 2457.08 | 794 | 780 | 160.6 |
| A | 0 | 226 | 6854 | 37.83 | 794 | 780 | 160.6 |
| A | 12 | 194 | 5676 | 30.5 | 794 | 780 | 160.6 |
| B | 15 | 35 | 58442 | 379.38 | 802 | 783 | 152.0 |
| B | 0 | 198 | 32505 | 208.72 | 802 | 783 | 152.0 |
| B | 3 | 209 | 23673 | 150.61 | 802 | 783 | 152.0 |
| C | 3 | 233 | 1679718 | 9655.59 | 751 | 759 | 173.9 |
| C | 14 | 238 | 118189 | 675.33 | 751 | 759 | 173.9 |
| C | 13 | 61 | 5313 | 26.19 | 751 | 759 | 173.9 |
| D | 5 | 222 | 553616 | 3012.58 | 757 | 737 | 183.5 |
| D | 12 | 218 | 193185 | 1048.63 | 757 | 737 | 183.5 |
| D | 2 | 33 | 93103 | 503.29 | 757 | 737 | 183.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
