| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000002440_16502cztM0_level2.evt | modeM0/AS1A05_174T01_9000002440_16502cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,694,080 | 90,472,320 |
| Size | 429.8 MB | 86.3 MB |
| Events in quadrant A | 3,262,433 | 573,888 |
| Events in quadrant B | 3,311,414 | 593,624 |
| Events in quadrant C | 3,584,174 | 565,202 |
| Events in quadrant D | 3,045,112 | 549,303 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13911 | 3 |
| B | 0 | 13939 | 2 |
| C | 0 | 14739 | 2 |
| D | 0 | 13600 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6563 | 33 | 0.502819% |
| B | 6563 | 48 | 0.731373% |
| C | 6563 | 63 | 0.959927% |
| D | 6563 | 19 | 0.289502% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7779 | 6564 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7779 | 6564 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7779 | 6564 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7779 | 6565 | 5 | 5 | 0.06% | 0.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 147147 | 900.62 | 802 | 787 | 162.5 |
| A | 3 | 1 | 33841 | 203.4 | 802 | 787 | 162.5 |
| A | 0 | 226 | 6947 | 37.91 | 802 | 787 | 162.5 |
| B | 15 | 35 | 30522 | 193.54 | 815 | 797 | 153.6 |
| B | 5 | 236 | 26676 | 168.5 | 815 | 797 | 153.6 |
| B | 12 | 111 | 18262 | 113.71 | 815 | 797 | 153.6 |
| C | 7 | 247 | 348901 | 1890.91 | 785 | 791 | 184.1 |
| C | 14 | 238 | 120416 | 649.8 | 785 | 791 | 184.1 |
| C | 3 | 233 | 50290 | 268.88 | 785 | 791 | 184.1 |
| D | 10 | 70 | 34035 | 174.19 | 786 | 765 | 191.0 |
| D | 2 | 234 | 20458 | 103.11 | 786 | 765 | 191.0 |
| D | 5 | 222 | 19773 | 99.52 | 786 | 765 | 191.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
