| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000002440_16506cztM0_level2.evt | modeM0/AS1A05_174T01_9000002440_16506cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,481,920 | 82,186,560 |
| Size | 501.1 MB | 78.4 MB |
| Events in quadrant A | 3,855,774 | 490,661 |
| Events in quadrant B | 3,920,819 | 499,103 |
| Events in quadrant C | 4,014,665 | 480,659 |
| Events in quadrant D | 3,595,318 | 477,923 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16652 | 3 |
| B | 0 | 16624 | 2 |
| C | 0 | 16642 | 2 |
| D | 0 | 16360 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7762 | 234 | 3.014687% |
| B | 7762 | 293 | 3.774800% |
| C | 7762 | 317 | 4.083999% |
| D | 7762 | 210 | 2.705488% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8288 | 7763 | 2 | 2 | 0.02% | 0.03% |  |
| B | 8288 | 7763 | 5 | 5 | 0.06% | 0.06% |  |
| C | 8288 | 7763 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8288 | 7763 | 1 | 1 | 0.01% | 0.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 158697 | 813.21 | 952 | 931 | 194.0 |
| A | 15 | 223 | 27454 | 136.71 | 952 | 931 | 194.0 |
| A | 0 | 226 | 8321 | 38.09 | 952 | 931 | 194.0 |
| B | 10 | 16 | 57729 | 303.14 | 955 | 929 | 187.4 |
| B | 4 | 173 | 35282 | 183.34 | 955 | 929 | 187.4 |
| B | 15 | 35 | 24161 | 123.99 | 955 | 929 | 187.4 |
| C | 3 | 233 | 141367 | 638.34 | 923 | 929 | 220.0 |
| C | 14 | 238 | 139054 | 627.83 | 923 | 929 | 220.0 |
| C | 7 | 247 | 137440 | 620.49 | 923 | 929 | 220.0 |
| D | 2 | 234 | 26631 | 111.0 | 939 | 912 | 231.7 |
| D | 12 | 110 | 15624 | 63.5 | 939 | 912 | 231.7 |
| D | 13 | 248 | 13619 | 54.84 | 939 | 912 | 231.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
