| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000002440_16515cztM0_level2.evt | modeM0/AS1A05_174T01_9000002440_16515cztM0_level2_quad_clean.evt |
| Size (bytes) | 554,382,720 | 96,721,920 |
| Size | 528.7 MB | 92.2 MB |
| Events in quadrant A | 3,592,377 | 625,795 |
| Events in quadrant B | 3,378,996 | 658,466 |
| Events in quadrant C | 6,087,277 | 594,677 |
| Events in quadrant D | 3,288,752 | 595,363 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14943 | 3 |
| B | 0 | 14101 | 2 |
| C | 0 | 22284 | 2 |
| D | 0 | 14077 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6521 | 77 | 1.180800% |
| B | 6521 | 56 | 0.858764% |
| C | 6521 | 1007 | 15.442417% |
| D | 6521 | 49 | 0.751418% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7837 | 6523 | 11 | 11 | 0.14% | 0.17% |  |
| B | 7837 | 6522 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7837 | 6522 | 735 | 735 | 9.38% | 11.27% |  |
| D | 7837 | 6522 | 23 | 23 | 0.29% | 0.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 416018 | 2540.17 | 820 | 806 | 163.5 |
| A | 15 | 223 | 20278 | 119.13 | 820 | 806 | 163.5 |
| A | 0 | 226 | 7055 | 38.23 | 820 | 806 | 163.5 |
| B | 15 | 35 | 59228 | 373.33 | 832 | 813 | 156.5 |
| B | 0 | 198 | 21065 | 129.43 | 832 | 813 | 156.5 |
| B | 12 | 111 | 18705 | 114.35 | 832 | 813 | 156.5 |
| C | 3 | 233 | 2998665 | 17030.71 | 758 | 763 | 176.0 |
| C | 14 | 238 | 117230 | 661.63 | 758 | 763 | 176.0 |
| C | 7 | 247 | 16051 | 86.85 | 758 | 763 | 176.0 |
| D | 10 | 70 | 166125 | 862.45 | 792 | 771 | 191.7 |
| D | 5 | 222 | 91843 | 475.01 | 792 | 771 | 191.7 |
| D | 1 | 52 | 31352 | 159.5 | 792 | 771 | 191.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
