| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_078T01_9000002462_16665cztM0_level2.evt | modeM0/AS1A05_078T01_9000002462_16665cztM0_level2_quad_clean.evt |
| Size (bytes) | 630,590,400 | 130,821,120 |
| Size | 601.4 MB | 124.8 MB |
| Events in quadrant A | 3,342,109 | 888,218 |
| Events in quadrant B | 3,824,076 | 898,616 |
| Events in quadrant C | 3,351,619 | 858,984 |
| Events in quadrant D | 8,081,810 | 804,260 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15220 | 3 |
| B | 0 | 16206 | 2 |
| C | 0 | 14971 | 2 |
| D | 0 | 29089 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7350 | 103 | 1.401361% |
| B | 7350 | 212 | 2.884354% |
| C | 7350 | 127 | 1.727891% |
| D | 7350 | 747 | 10.163265% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7541 | 7353 | 6 | 6 | 0.08% | 0.08% |  |
| B | 7541 | 7353 | 26 | 26 | 0.34% | 0.35% |  |
| C | 7541 | 7353 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7541 | 7353 | 612 | 612 | 8.12% | 8.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 86083 | 495.14 | 842 | 824 | 172.2 |
| A | 9 | 143 | 9240 | 48.88 | 842 | 824 | 172.2 |
| A | 0 | 226 | 7326 | 37.76 | 842 | 824 | 172.2 |
| B | 15 | 35 | 208989 | 1295.61 | 844 | 821 | 160.7 |
| B | 0 | 229 | 91475 | 564.22 | 844 | 821 | 160.7 |
| B | 7 | 220 | 72236 | 444.48 | 844 | 821 | 160.7 |
| C | 14 | 238 | 124543 | 654.5 | 811 | 815 | 189.0 |
| C | 3 | 233 | 42581 | 220.94 | 811 | 815 | 189.0 |
| C | 7 | 247 | 11441 | 56.21 | 811 | 815 | 189.0 |
| D | 1 | 52 | 4986250 | 25861.21 | 796 | 772 | 192.8 |
| D | 2 | 234 | 33419 | 169.35 | 796 | 772 | 192.8 |
| D | 10 | 70 | 30681 | 155.14 | 796 | 772 | 192.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
