| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_004T05_9000002488_16764cztM0_level2.evt | modeM0/AS1A05_004T05_9000002488_16764cztM0_level2_quad_clean.evt |
| Size (bytes) | 629,899,200 | 90,158,400 |
| Size | 600.7 MB | 86.0 MB |
| Events in quadrant A | 3,214,135 | 606,431 |
| Events in quadrant B | 3,437,463 | 601,815 |
| Events in quadrant C | 4,003,401 | 583,096 |
| Events in quadrant D | 7,970,629 | 474,224 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13841 | 2 |
| B | 0 | 14487 | 1 |
| C | 0 | 16325 | 1 |
| D | 0 | 28112 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6659 | 73 | 1.096261% |
| B | 6659 | 98 | 1.471692% |
| C | 6659 | 164 | 2.462832% |
| D | 6659 | 1780 | 26.730740% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7450 | 6661 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7450 | 6661 | 8 | 8 | 0.11% | 0.12% |  |
| C | 7450 | 6661 | 11 | 11 | 0.15% | 0.17% |  |
| D | 7450 | 6661 | 1476 | 1476 | 19.81% | 22.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 57478 | 341.93 | 821 | 802 | 165.8 |
| A | 0 | 226 | 7332 | 39.4 | 821 | 802 | 165.8 |
| A | 12 | 194 | 6067 | 31.76 | 821 | 802 | 165.8 |
| B | 15 | 35 | 94594 | 603.82 | 813 | 794 | 155.3 |
| B | 5 | 236 | 38520 | 242.86 | 813 | 794 | 155.3 |
| B | 3 | 209 | 22916 | 142.41 | 813 | 794 | 155.3 |
| C | 3 | 233 | 594904 | 3228.09 | 787 | 794 | 184.0 |
| C | 0 | 207 | 212220 | 1148.78 | 787 | 794 | 184.0 |
| C | 14 | 238 | 121659 | 656.72 | 787 | 794 | 184.0 |
| D | 12 | 110 | 2403081 | 13461.89 | 730 | 709 | 178.5 |
| D | 1 | 52 | 1483106 | 8306.73 | 730 | 709 | 178.5 |
| D | 13 | 232 | 940589 | 5266.7 | 730 | 709 | 178.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
