| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_004T07_9000002492_16787cztM0_level2.evt | modeM0/AS1A05_004T07_9000002492_16787cztM0_level2_quad_clean.evt |
| Size (bytes) | 672,621,120 | 75,942,720 |
| Size | 641.5 MB | 72.4 MB |
| Events in quadrant A | 4,054,528 | 464,874 |
| Events in quadrant B | 3,833,672 | 477,296 |
| Events in quadrant C | 4,821,755 | 454,002 |
| Events in quadrant D | 7,162,866 | 390,925 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16522 | 3 |
| B | 0 | 15850 | 2 |
| C | 0 | 19028 | 2 |
| D | 0 | 26285 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7354 | 169 | 2.298069% |
| B | 7354 | 95 | 1.291814% |
| C | 7354 | 150 | 2.039706% |
| D | 7354 | 1268 | 17.242317% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9375 | 7357 | 100 | 100 | 1.07% | 1.36% |  |
| B | 9375 | 7357 | 12 | 12 | 0.13% | 0.16% |  |
| C | 9375 | 7357 | 3 | 3 | 0.03% | 0.04% |  |
| D | 9375 | 7357 | 1021 | 1021 | 10.89% | 13.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 506848 | 2708.41 | 919 | 899 | 186.8 |
| A | 14 | 4 | 9245 | 44.68 | 919 | 899 | 186.8 |
| A | 0 | 226 | 8055 | 38.31 | 919 | 899 | 186.8 |
| B | 15 | 35 | 97280 | 547.71 | 924 | 901 | 176.0 |
| B | 0 | 229 | 63667 | 356.69 | 924 | 901 | 176.0 |
| B | 3 | 209 | 20870 | 113.48 | 924 | 901 | 176.0 |
| C | 3 | 233 | 1144743 | 5601.36 | 882 | 889 | 204.2 |
| C | 14 | 238 | 138873 | 675.69 | 882 | 889 | 204.2 |
| C | 0 | 207 | 62509 | 301.75 | 882 | 889 | 204.2 |
| D | 1 | 52 | 3567296 | 17407.61 | 845 | 822 | 204.9 |
| D | 15 | 0 | 182306 | 885.81 | 845 | 822 | 204.9 |
| D | 12 | 110 | 74405 | 359.15 | 845 | 822 | 204.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
