| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_004T03_9000002508_16897cztM0_level2.evt | modeM0/AS1A05_004T03_9000002508_16897cztM0_level2_quad_clean.evt |
| Size (bytes) | 542,543,040 | 103,999,680 |
| Size | 517.4 MB | 99.2 MB |
| Events in quadrant A | 4,012,192 | 668,908 |
| Events in quadrant B | 3,894,961 | 674,098 |
| Events in quadrant C | 3,765,863 | 650,933 |
| Events in quadrant D | 4,250,497 | 635,344 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16994 | 2 |
| B | 0 | 16420 | 2 |
| C | 0 | 16115 | 2 |
| D | 0 | 17654 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7474 | 203 | 2.716082% |
| B | 7474 | 140 | 1.873160% |
| C | 7474 | 126 | 1.685844% |
| D | 7473 | 121 | 1.619162% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7840 | 7476 | 41 | 41 | 0.52% | 0.55% |  |
| B | 7840 | 7476 | 3 | 3 | 0.04% | 0.04% |  |
| C | 7840 | 7476 | 6 | 6 | 0.08% | 0.08% |  |
| D | 7839 | 7475 | 42 | 42 | 0.54% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 520916 | 2873.43 | 897 | 877 | 181.0 |
| A | 12 | 189 | 34877 | 187.86 | 897 | 877 | 181.0 |
| A | 4 | 2 | 10214 | 51.59 | 897 | 877 | 181.0 |
| B | 15 | 35 | 157813 | 919.9 | 894 | 873 | 170.6 |
| B | 4 | 216 | 92902 | 539.42 | 894 | 873 | 170.6 |
| B | 0 | 229 | 36883 | 211.07 | 894 | 873 | 170.6 |
| C | 3 | 233 | 243202 | 1200.28 | 862 | 868 | 201.9 |
| C | 14 | 238 | 132121 | 650.1 | 862 | 868 | 201.9 |
| C | 0 | 207 | 22442 | 106.86 | 862 | 868 | 201.9 |
| D | 1 | 52 | 557786 | 2565.81 | 881 | 855 | 217.1 |
| D | 10 | 199 | 147531 | 675.74 | 881 | 855 | 217.1 |
| D | 12 | 235 | 71175 | 323.97 | 881 | 855 | 217.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
