| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_225T02_9000002510_16908cztM0_level2.evt | modeM0/AS1A05_225T02_9000002510_16908cztM0_level2_quad_clean.evt |
| Size (bytes) | 189,443,520 | 37,209,600 |
| Size | 180.7 MB | 35.5 MB |
| Events in quadrant A | 2,461,884 | 225,059 |
| Events in quadrant B | 1,021,307 | 266,066 |
| Events in quadrant C | 1,016,888 | 249,131 |
| Events in quadrant D | 1,101,171 | 242,880 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8698 | 4 |
| B | 0 | 4222 | 1 |
| C | 0 | 4233 | 1 |
| D | 0 | 4566 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 40 | 0 |
| B | 0 | 40 | 0 |
| C | 0 | 40 | 0 |
| D | 0 | 40 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1971 | 687 | 34.855403% |
| B | 1971 | 108 | 5.479452% |
| C | 1971 | 114 | 5.783866% |
| D | 1971 | 112 | 5.682395% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2937 | 1973 | 334 | 334 | 11.37% | 16.93% |  |
| B | 2937 | 1973 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2937 | 1973 | 0 | 0 | 0.00% | 0.00% |  |
| D | 2937 | 1973 | 26 | 26 | 0.89% | 1.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 1564290 | 33010.75 | 228 | 223 | 47.4 |
| A | 12 | 189 | 15437 | 321.1 | 228 | 223 | 47.4 |
| A | 0 | 226 | 2084 | 39.28 | 228 | 223 | 47.4 |
| B | 0 | 229 | 9515 | 183.4 | 253 | 246 | 50.5 |
| B | 15 | 35 | 8890 | 171.03 | 253 | 246 | 50.5 |
| B | 12 | 111 | 5706 | 108.03 | 253 | 246 | 50.5 |
| C | 3 | 233 | 50747 | 904.23 | 237 | 238 | 55.9 |
| C | 14 | 238 | 37275 | 663.05 | 237 | 238 | 55.9 |
| C | 13 | 61 | 1704 | 26.24 | 237 | 238 | 55.9 |
| D | 1 | 52 | 164865 | 2743.31 | 244 | 235 | 60.0 |
| D | 2 | 234 | 7512 | 121.26 | 244 | 235 | 60.0 |
| D | 15 | 145 | 5303 | 84.45 | 244 | 235 | 60.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
