| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_206T01_9000002518_16944cztM0_level2.evt | modeM0/AS1A05_206T01_9000002518_16944cztM0_level2_quad_clean.evt |
| Size (bytes) | 625,527,360 | 105,592,320 |
| Size | 596.5 MB | 100.7 MB |
| Events in quadrant A | 7,463,480 | 631,174 |
| Events in quadrant B | 3,823,406 | 708,415 |
| Events in quadrant C | 3,507,132 | 683,260 |
| Events in quadrant D | 3,658,525 | 669,430 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26942 | 2 |
| B | 0 | 16192 | 2 |
| C | 0 | 15023 | 2 |
| D | 0 | 15973 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7251 | 1347 | 18.576748% |
| B | 7251 | 120 | 1.654944% |
| C | 7252 | 66 | 0.910094% |
| D | 7251 | 100 | 1.379120% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9027 | 7254 | 1136 | 1136 | 12.58% | 15.66% |  |
| B | 9027 | 7254 | 22 | 22 | 0.24% | 0.30% |  |
| C | 9028 | 7255 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9027 | 7254 | 47 | 47 | 0.52% | 0.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 4259358 | 26370.39 | 801 | 784 | 161.5 |
| A | 15 | 190 | 64625 | 395.32 | 801 | 784 | 161.5 |
| A | 12 | 189 | 28311 | 170.46 | 801 | 784 | 161.5 |
| B | 15 | 35 | 167497 | 1014.07 | 860 | 836 | 164.3 |
| B | 0 | 229 | 116682 | 704.88 | 860 | 836 | 164.3 |
| B | 0 | 197 | 74568 | 448.63 | 860 | 836 | 164.3 |
| C | 3 | 233 | 156783 | 808.51 | 825 | 831 | 192.9 |
| C | 14 | 238 | 126327 | 650.62 | 825 | 831 | 192.9 |
| C | 13 | 61 | 5778 | 25.65 | 825 | 831 | 192.9 |
| D | 1 | 52 | 365122 | 1780.65 | 831 | 805 | 204.6 |
| D | 10 | 70 | 71143 | 343.79 | 831 | 805 | 204.6 |
| D | 2 | 234 | 28772 | 136.69 | 831 | 805 | 204.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
