| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_188T01_9000002520_16959cztM0_level2.evt | modeM0/AS1A05_188T01_9000002520_16959cztM0_level2_quad_clean.evt |
| Size (bytes) | 459,642,240 | 100,540,800 |
| Size | 438.3 MB | 95.9 MB |
| Events in quadrant A | 3,074,443 | 651,200 |
| Events in quadrant B | 3,406,654 | 666,254 |
| Events in quadrant C | 3,732,966 | 637,395 |
| Events in quadrant D | 3,253,578 | 625,484 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13585 | 2 |
| B | 0 | 14492 | 2 |
| C | 0 | 15432 | 2 |
| D | 0 | 14161 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6660 | 39 | 0.585586% |
| B | 6661 | 109 | 1.636391% |
| C | 6661 | 92 | 1.381174% |
| D | 6661 | 37 | 0.555472% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8621 | 6663 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8622 | 6664 | 9 | 9 | 0.10% | 0.14% |  |
| C | 8622 | 6664 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8622 | 6664 | 6 | 6 | 0.07% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 11353 | 65.16 | 795 | 776 | 162.3 |
| A | 0 | 226 | 6980 | 38.22 | 795 | 776 | 162.3 |
| A | 12 | 189 | 6642 | 36.14 | 795 | 776 | 162.3 |
| B | 15 | 35 | 139593 | 900.21 | 803 | 783 | 154.2 |
| B | 3 | 64 | 49273 | 314.47 | 803 | 783 | 154.2 |
| B | 12 | 111 | 18204 | 112.98 | 803 | 783 | 154.2 |
| C | 3 | 233 | 599868 | 3307.13 | 772 | 778 | 181.2 |
| C | 14 | 238 | 120206 | 659.27 | 772 | 778 | 181.2 |
| C | 13 | 61 | 5288 | 24.9 | 772 | 778 | 181.2 |
| D | 1 | 52 | 194544 | 1019.23 | 775 | 752 | 190.1 |
| D | 7 | 38 | 38525 | 198.66 | 775 | 752 | 190.1 |
| D | 2 | 152 | 33798 | 173.8 | 775 | 752 | 190.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
