| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_143T01_9000002524_16992cztM0_level2.evt | modeM0/AS1A05_143T01_9000002524_16992cztM0_level2_quad_clean.evt |
| Size (bytes) | 529,695,360 | 104,063,040 |
| Size | 505.2 MB | 99.2 MB |
| Events in quadrant A | 3,270,257 | 678,267 |
| Events in quadrant B | 3,452,556 | 704,718 |
| Events in quadrant C | 3,778,914 | 679,396 |
| Events in quadrant D | 5,105,287 | 641,704 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13649 | 2 |
| B | 0 | 14167 | 2 |
| C | 0 | 15434 | 2 |
| D | 0 | 19528 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6425 | 23 | 0.357977% |
| B | 6425 | 35 | 0.544747% |
| C | 6425 | 73 | 1.136187% |
| D | 6425 | 220 | 3.424125% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7781 | 6427 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7781 | 6427 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7781 | 6427 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7781 | 6427 | 146 | 146 | 1.88% | 2.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 64010 | 380.92 | 834 | 819 | 165.9 |
| A | 0 | 226 | 7398 | 39.66 | 834 | 819 | 165.9 |
| A | 12 | 194 | 6149 | 32.13 | 834 | 819 | 165.9 |
| B | 3 | 64 | 52505 | 329.26 | 843 | 825 | 157.0 |
| B | 0 | 229 | 44910 | 280.87 | 843 | 825 | 157.0 |
| B | 3 | 209 | 34204 | 212.66 | 843 | 825 | 157.0 |
| C | 3 | 233 | 438524 | 2293.09 | 824 | 833 | 190.9 |
| C | 14 | 238 | 128741 | 670.12 | 824 | 833 | 190.9 |
| C | 13 | 61 | 5731 | 25.66 | 824 | 833 | 190.9 |
| D | 1 | 52 | 1948805 | 9966.62 | 814 | 793 | 195.5 |
| D | 7 | 223 | 34228 | 171.06 | 814 | 793 | 195.5 |
| D | 2 | 152 | 24019 | 118.83 | 814 | 793 | 195.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
