| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_038T01_9000002530_17046cztM0_level2.evt | modeM0/AS1T03_038T01_9000002530_17046cztM0_level2_quad_clean.evt |
| Size (bytes) | 557,968,320 | 88,369,920 |
| Size | 532.1 MB | 84.3 MB |
| Events in quadrant A | 3,101,034 | 560,333 |
| Events in quadrant B | 3,289,117 | 572,204 |
| Events in quadrant C | 6,619,128 | 530,076 |
| Events in quadrant D | 3,430,755 | 542,478 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13877 | 2 |
| B | 0 | 14278 | 2 |
| C | 0 | 24319 | 6 |
| D | 0 | 15114 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6753 | 31 | 0.459055% |
| B | 6753 | 65 | 0.962535% |
| C | 6752 | 735 | 10.885664% |
| D | 6752 | 148 | 2.191943% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7804 | 6755 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7804 | 6755 | 20 | 20 | 0.26% | 0.30% |  |
| C | 7803 | 6754 | 198 | 198 | 2.54% | 2.93% |  |
| D | 7803 | 6754 | 91 | 91 | 1.17% | 1.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 10215 | 58.14 | 804 | 786 | 162.2 |
| A | 0 | 226 | 6936 | 37.92 | 804 | 786 | 162.2 |
| A | 3 | 137 | 5980 | 32.03 | 804 | 786 | 162.2 |
| B | 4 | 173 | 82663 | 535.55 | 805 | 784 | 152.9 |
| B | 0 | 229 | 27670 | 175.85 | 805 | 784 | 152.9 |
| B | 12 | 111 | 18155 | 113.62 | 805 | 784 | 152.9 |
| C | 3 | 233 | 3517482 | 19887.34 | 760 | 763 | 176.8 |
| C | 14 | 238 | 117698 | 661.28 | 760 | 763 | 176.8 |
| C | 7 | 247 | 17219 | 93.06 | 760 | 763 | 176.8 |
| D | 10 | 70 | 272263 | 1435.63 | 783 | 760 | 189.1 |
| D | 2 | 14 | 135331 | 711.57 | 783 | 760 | 189.1 |
| D | 5 | 222 | 28438 | 146.35 | 783 | 760 | 189.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
