| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_038T01_9000002530_17048cztM0_level2.evt | modeM0/AS1T03_038T01_9000002530_17048cztM0_level2_quad_clean.evt |
| Size (bytes) | 186,183,360 | 21,646,080 |
| Size | 177.6 MB | 20.6 MB |
| Events in quadrant A | 1,006,206 | 127,220 |
| Events in quadrant B | 1,049,695 | 130,643 |
| Events in quadrant C | 2,155,779 | 121,155 |
| Events in quadrant D | 1,281,850 | 123,192 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 1 | 273359709408 | 0 |
| B | 1 | -1 | -1 |
| C | 1 | -1 | -1 |
| D | 1 | -1 | -1 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4426 | 1 |
| B | 0 | 4533 | 1 |
| C | 0 | 7928 | 1 |
| D | 0 | 5235 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42 | 0 |
| B | 0 | 42 | 0 |
| C | 0 | 42 | 0 |
| D | 0 | 42 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2106 | 6 | 0.284900% |
| B | 2106 | 9 | 0.427350% |
| C | 2106 | 97 | 4.605888% |
| D | 2106 | 87 | 4.131054% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2107 | 2107 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2107 | 2107 | 0 | 0 | 0.00% | 0.00% |  |
| C | 2107 | 2107 | 4 | 4 | 0.19% | 0.19% |  |
| D | 2107 | 2107 | 69 | 69 | 3.27% | 3.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 8035 | 144.21 | 259 | 253 | 54.0 |
| A | 0 | 226 | 2260 | 37.19 | 259 | 253 | 54.0 |
| A | 12 | 194 | 1898 | 30.48 | 259 | 253 | 54.0 |
| B | 0 | 229 | 12240 | 233.52 | 263 | 256 | 51.3 |
| B | 0 | 219 | 9922 | 188.35 | 263 | 256 | 51.3 |
| B | 12 | 111 | 5790 | 107.83 | 263 | 256 | 51.3 |
| C | 3 | 233 | 1116494 | 18302.48 | 255 | 257 | 61.0 |
| C | 14 | 238 | 38779 | 631.63 | 255 | 257 | 61.0 |
| C | 7 | 247 | 5303 | 82.74 | 255 | 257 | 61.0 |
| D | 10 | 70 | 205018 | 3281.75 | 253 | 246 | 62.4 |
| D | 1 | 52 | 58484 | 933.34 | 253 | 246 | 62.4 |
| D | 5 | 222 | 57902 | 924.02 | 253 | 246 | 62.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
