| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_004T03_9000002538_17111cztM0_level2.evt | modeM0/AS1A05_004T03_9000002538_17111cztM0_level2_quad_clean.evt |
| Size (bytes) | 465,678,720 | 75,700,800 |
| Size | 444.1 MB | 72.2 MB |
| Events in quadrant A | 3,173,749 | 463,727 |
| Events in quadrant B | 3,309,127 | 469,545 |
| Events in quadrant C | 3,432,011 | 447,453 |
| Events in quadrant D | 3,726,424 | 437,743 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13894 | 2 |
| B | 0 | 14140 | 2 |
| C | 0 | 14219 | 2 |
| D | 0 | 15772 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6789 | 47 | 0.692296% |
| B | 6789 | 59 | 0.869053% |
| C | 6789 | 80 | 1.178377% |
| D | 6789 | 110 | 1.620268% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7769 | 6790 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7769 | 6790 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7769 | 6790 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7769 | 6790 | 87 | 87 | 1.12% | 1.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 10725 | 59.86 | 822 | 803 | 165.8 |
| A | 0 | 226 | 7040 | 37.63 | 822 | 803 | 165.8 |
| A | 12 | 194 | 6085 | 31.87 | 822 | 803 | 165.8 |
| B | 3 | 209 | 42500 | 263.79 | 828 | 805 | 158.1 |
| B | 12 | 111 | 18584 | 112.48 | 828 | 805 | 158.1 |
| B | 11 | 111 | 15888 | 95.42 | 828 | 805 | 158.1 |
| C | 3 | 233 | 201414 | 1087.3 | 791 | 797 | 184.5 |
| C | 14 | 238 | 122539 | 659.81 | 791 | 797 | 184.5 |
| C | 9 | 54 | 22955 | 120.09 | 791 | 797 | 184.5 |
| D | 12 | 32 | 562261 | 2903.59 | 792 | 768 | 193.4 |
| D | 5 | 222 | 122272 | 628.32 | 792 | 768 | 193.4 |
| D | 10 | 70 | 30954 | 156.1 | 792 | 768 | 193.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
