| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002548_17171cztM0_level2.evt | modeM0/AS1A05_185T04_9000002548_17171cztM0_level2_quad_clean.evt |
| Size (bytes) | 561,000,960 | 75,208,320 |
| Size | 535.0 MB | 71.7 MB |
| Events in quadrant A | 3,440,237 | 459,850 |
| Events in quadrant B | 3,616,460 | 462,449 |
| Events in quadrant C | 3,717,364 | 443,515 |
| Events in quadrant D | 5,715,540 | 398,116 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15197 | 1 |
| B | 0 | 15505 | 1 |
| C | 0 | 15471 | 2 |
| D | 0 | 22312 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7365 | 198 | 2.688391% |
| B | 7366 | 222 | 3.013847% |
| C | 7365 | 233 | 3.163612% |
| D | 7365 | 854 | 11.595384% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7535 | 7366 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7536 | 7367 | 5 | 5 | 0.07% | 0.07% |  |
| C | 7535 | 7366 | 5 | 5 | 0.07% | 0.07% |  |
| D | 7535 | 7366 | 639 | 639 | 8.48% | 8.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 31629 | 170.63 | 883 | 862 | 180.3 |
| A | 12 | 96 | 13308 | 69.02 | 883 | 862 | 180.3 |
| A | 0 | 226 | 7550 | 37.09 | 883 | 862 | 180.3 |
| B | 0 | 219 | 71382 | 405.93 | 885 | 860 | 173.7 |
| B | 0 | 197 | 56883 | 322.47 | 885 | 860 | 173.7 |
| B | 12 | 111 | 21047 | 116.2 | 885 | 860 | 173.7 |
| C | 3 | 233 | 217718 | 1086.44 | 850 | 852 | 199.6 |
| C | 14 | 238 | 129621 | 645.1 | 850 | 852 | 199.6 |
| C | 4 | 254 | 55075 | 271.64 | 850 | 852 | 199.6 |
| D | 5 | 222 | 2457026 | 12070.58 | 832 | 807 | 203.5 |
| D | 10 | 199 | 63795 | 309.54 | 832 | 807 | 203.5 |
| D | 2 | 234 | 26837 | 127.92 | 832 | 807 | 203.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
