| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002548_17176cztM0_level2.evt | modeM0/AS1A05_185T04_9000002548_17176cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,088,640 | 101,462,400 |
| Size | 481.7 MB | 96.8 MB |
| Events in quadrant A | 3,284,315 | 670,006 |
| Events in quadrant B | 3,353,694 | 670,104 |
| Events in quadrant C | 3,516,687 | 633,333 |
| Events in quadrant D | 4,678,837 | 623,778 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14246 | 2 |
| B | 0 | 14382 | 2 |
| C | 0 | 14709 | 2 |
| D | 0 | 18635 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6812 | 73 | 1.071638% |
| B | 6812 | 72 | 1.056958% |
| C | 6812 | 146 | 2.143277% |
| D | 6812 | 238 | 3.493834% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8577 | 6812 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8577 | 6812 | 6 | 6 | 0.07% | 0.09% |  |
| C | 8577 | 6813 | 15 | 15 | 0.17% | 0.22% |  |
| D | 8577 | 6812 | 153 | 153 | 1.78% | 2.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 61882 | 363.39 | 833 | 815 | 168.0 |
| A | 15 | 174 | 18077 | 102.72 | 833 | 815 | 168.0 |
| A | 0 | 226 | 7327 | 38.75 | 833 | 815 | 168.0 |
| B | 7 | 220 | 42901 | 264.78 | 824 | 803 | 159.0 |
| B | 0 | 189 | 35664 | 219.26 | 824 | 803 | 159.0 |
| B | 0 | 197 | 24985 | 152.1 | 824 | 803 | 159.0 |
| C | 4 | 254 | 167666 | 909.4 | 786 | 789 | 183.5 |
| C | 3 | 233 | 159333 | 863.99 | 786 | 789 | 183.5 |
| C | 14 | 238 | 121595 | 658.33 | 786 | 789 | 183.5 |
| D | 1 | 52 | 1173110 | 5998.29 | 803 | 779 | 195.4 |
| D | 5 | 222 | 333302 | 1701.37 | 803 | 779 | 195.4 |
| D | 12 | 233 | 36614 | 183.35 | 803 | 779 | 195.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
