| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_185T04_9000002548_17191cztM0_level2.evt | modeM0/AS1A05_185T04_9000002548_17191cztM0_level2_quad_clean.evt |
| Size (bytes) | 464,627,520 | 96,698,880 |
| Size | 443.1 MB | 92.2 MB |
| Events in quadrant A | 3,034,443 | 643,004 |
| Events in quadrant B | 3,208,449 | 639,994 |
| Events in quadrant C | 4,113,891 | 600,420 |
| Events in quadrant D | 3,287,439 | 606,282 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13119 | 1 |
| B | 0 | 13670 | 1 |
| C | 0 | 16233 | 1 |
| D | 0 | 13971 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6290 | 71 | 1.128776% |
| B | 6291 | 83 | 1.319345% |
| C | 6291 | 167 | 2.654586% |
| D | 6291 | 103 | 1.637260% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7290 | 6290 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7291 | 6291 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7291 | 6291 | 12 | 12 | 0.16% | 0.19% |  |
| D | 7291 | 6291 | 35 | 35 | 0.48% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 63337 | 399.3 | 772 | 755 | 156.7 |
| A | 0 | 226 | 6824 | 38.72 | 772 | 755 | 156.7 |
| A | 12 | 194 | 5751 | 31.87 | 772 | 755 | 156.7 |
| B | 0 | 219 | 77076 | 523.64 | 763 | 744 | 145.8 |
| B | 4 | 216 | 39940 | 268.88 | 763 | 744 | 145.8 |
| B | 7 | 220 | 27594 | 184.19 | 763 | 744 | 145.8 |
| C | 3 | 233 | 1113446 | 6556.82 | 727 | 733 | 169.7 |
| C | 14 | 238 | 116769 | 683.76 | 727 | 733 | 169.7 |
| C | 9 | 54 | 31555 | 181.62 | 727 | 733 | 169.7 |
| D | 5 | 222 | 178847 | 973.03 | 751 | 729 | 183.1 |
| D | 10 | 70 | 113173 | 614.26 | 751 | 729 | 183.1 |
| D | 1 | 52 | 62500 | 337.44 | 751 | 729 | 183.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
